10/30 Frequency inverters
Assigned switching and protective elements
2010 CA08103002Z-EN
Engineering
Part no. Motor Frequency inverters
Protection type IP21 Protection type IP54 Assigned motor rating
(ULN, 50/60 Hz) Motor current1) Rated operational current
Frequency inverters Mains current
(DC link choke)
P Ie Ie ILN
kW A A A
HMX32… frequency inverters
Three-phase mains connection (3 AC 230 V/240 V)
HMX32AG3D721-B HMX32AG3D722-B 0.75 3.2 3.7
HMX32AG4D821-B HMX32AG4D822-B 1.1 4.6 4.8
HMX32AG6D621-B HMX32AG6D622-B 1.5 6.3 6.6
HMX32AG8D021-B HMX32AG8D022-B 1.5 6.3 8
HMX32AG01121-B HMX32AG01122-B 2.2 8.7 11
HMX32AG01221-B HMX32AG01222-B 3 11.5 12.5
HMX32AG01821-B HMX32AG01822-B 4 14.8 18
HMX32AG02421-B HMX32AG02422-B 5.5 19.6 24.2
HMX32AG03121-B HMX32AG03122-B 7.5 26.4 31
HMX32AG04821-B HMX32AG04822-B 11 38 48
HMX32AG06221-B HMX32AG06222-B 15 51 62
HMX32AG07721-B HMX32AG07722-B 18.5 63 77
HMX32AG08821-B HMX32AG08822-B 22 71 88
HMX32AG10621-B HMX32AG10622-B 30 96 106
HMX32AG14321-B HMX32AG14322-B 37 117 143
HMX32AG17021-B HMX32AG17022-B 45 141 170
HMX32AG20521-B HMX32AG20522-B 55 173 208
HMX32AG26121-B HMX32AG26122-B 75 233 261
HMX32AG31021-B HMX32AG31022-B 90 279 310
HMX34… frequency inverters
Three-phase mains connection (3 AC 400 V/480 V)
HMX34AG3D421-B HMX34AG3D422-B 1.1 2.6 3.4
HMX34AG4D821-B HMX34AG4D822-B 1.5 3.6 4.8
HMX34AG5D621-B HMX34AG5D622-B 2.2 5 5.6
HMX34AG8D021-B HMX34AG8D022-B 3 6.6 8
HMX34AG9D621-B HMX34AG9D622-B 4 8.5 9.6
HMX34AG01221-B HMX34AG01222-B 5.5 11.3 12
HMX34AG01621-B HMX34AG01622-B 7.5 15.2 16
HMX34AG02321-B HMX34AG02322-B 11 21.7 23
HMX34AG03121-B HMX34AG03122-B 15 29.3 31
HMX34AG03821-B HMX34AG03822-B 18.5 36 38
HMX34AG04621-B HMX34AG04622-B 22 41 46
HMX34AG06121-B HMX34AG06122-B 30 55 61
HMX34AG07221-B HMX34AG07222-B 37 68 72
HMX34AG08721-B HMX34AG08722-B 45 81 87
HMX34AG10521-B HMX34AG10522-B 55 99 105
HMX34AG14021-B HMX34AG14022-B 75 134 140
HMX34AG17021-B HMX34AG17022-B 90 161 170
HMX34AG20521-B HMX34AG20522-B 110 196 205
HMX34AG26121-B HMX34AG26122-B 132 231 261
HMX34AG31021-B HMX34AG31022-B 160 279 310
Notes All data apply at an ambient air temperature of up to +40 °C.
1) The rated motor currents apply to normal internally and surface-cooled three-phase motors with 1500 rpm at 50 Hz or 1800 rpm at 60 Hz.
2) At motor currents above 100 A use frame size DEX-LM3-150.
DIL mains contactor ￫chapter 5
DEX-LM3-… motor chokes ￫Page 10/21
SFB400/... sine-wave filters please enquire
H-Max™
