428 / 439
10/32
Frequency inverters
MMX12... ,MMX32...
2010
CA08103002Z-EN
www.eaton.comMMX12... ,MMX32...
Technical data
MMX12...
MMX...1D7...
MMX...2D4...
Power side (primary side)
Number of phases
1 (
L and N) or
2 (
e.g. L1 and L2)
1 (
L and N) or
2 (
e.g. L1 and L2)
Mains connection voltage
U
LN
IEC (50/60Hz)
V
208 -15 % - 240
+10 %
208 -15 % - 240
+10 %
UL/CSA (45 - 66 Hz ±0 %)
V
177 - 264
±0 %
177 - 264
±0 %
Rated operational voltage
U
e
V
230
230
Rated operational current
I
e
A
1.7
2.4
Input current
I
LN
A
4.2
5.7
Overload current for 60 s every 600 s at 50 °C
A
2.6
3.6
Starting current for 2 s every 20 s at 50 °C
A
3.4
4.8
Maximum leakage current to ground (PE) without motor
I
PE
mA 15.4
15.4
Apparent power at rated operation 230 V
kVA 0.68
0.96
Apparent power at rated operation 240 V
kVA 0.71
0.99
Assigned motor rating (230 V)
P
kWh 0.25
0.37
Assigned motor rating (230 V)
P
HP
1/3
1)
1/2
Braking torque
Standard
Max. 30 % M
N
Max. 30 % M
N
DC braking
Max. 100 % of rated operational current I
e
,
adjustable
Pulse frequency
f
PWM
kHz
6 (
adjustable 1 – 16)
6 (
adjustable 1 – 16)
Heat dissipation at rated operational current I
e
P
V
W 17.9
24.6
Efficiency
η
0.93
0.93
Fan (built into device, temperature-controlled)
•
•
Frame size
FS1
FS1
Weight
m kg
0.55
0.55
Notes
1)
Not a standardized output
MMX32...
MMX...1D7
...
MMX...2D4...
Power side (primary side):
Number of phases
3 (
L1, L2, L3)
3 (
L1, L2, L3)
Mains connection voltage
U
LN
U
LN
IEC (50/60Hz)
208 -15 % - 240
+10 %
208 -15 % - 240
+10 %
UL/CSA (45 - 66 Hz ±0 %)
177 - 264
±0 %
177 - 264
±0 %
Rated operational voltage
U
e
U
e
230
230
Rated operational current
I
e
I
e
1.7
2.4
Input current
I
LN
I
LN
2.7
3.5
Overload current for 60 s every 600 s at 50 °C
2.6
3.6
Starting current for 2 s every 20 s at 50 °C
3.4
4.8
Maximum leakage current to ground (PE) without motor
I
PE
8.6
8.6
Apparent power at rated operation 230 V
0.68
0.96
Apparent power at rated operation 240 V
0.71
0.99
Assigned motor rating (230 V)
P
0.25
0.37
Assigned motor rating (230 V)
P
1/3
1)
1/2
Braking torque
Standard
Max. 30 % M
N
Max. 30 % M
N
DC braking
Max. 100 % of rated operational current I
e
,
adjustable
Pulse frequency
f
PWM
6 (
adjustable 1 – 16)
6 (
adjustable 1 – 16)
Heat dissipation at rated operational current I
e
P
V
17.4
23.7
Efficiency
η
η
0.93
0.94
Fan (built into device, temperature-controlled)
•
•
Frame size
FS1
FS1
Weight
m 0.55
0.55
Notes
1)
Guide value, not a standardized output
