Frequency inverters
Assigned switching and protective elements
2010
CA08103002Z-EN
www.eaton.comAssigned switchingandprotectiveelements
Part no.
Motor
Frequency inverters
Mains supply
With internal
radio interference
suppression filter
Without internal
radio interference
suppression filter
Assigned
motor rating
(
U
LN
, 50/60
Hz)
Motor current
1)
Rated operational
current
Frequency inverters
Mains current
Without mains
choke
Short-circuit and
cable protection
(
fuse)
2)
P
I
e
I
e
I
LN
kW
A
A
A
MMX12… frequency inverters
Single-phase mains connection (1 AC 230 V/240 V)
MMX12AA1D7F0-0
MMX12AA1D7N0-0 0.25
1.4
1.7
4.2
FAZ-B10/1N
MMX12AA2D4F0-0
MMX12AA2D4N0-0 0.37
2
2.4
5.7
FAZ-B10/1N
MMX12AA2D8F0-0
MMX12AA2D8N0-0 0.55
2.7
2.8
6.6
FAZ-B10/1N
MMX12AA3D7F0-0
MMX12AA3D7N0-0 0.75
3.2
3.7
8.3
FAZ-B10/1N
MMX12AA4D8F0-0
MMX12AA4D8N0-0 1.1
4.6
4.8
11.2
FAZ-B20/1N
MMX12AA7D0F0-0
MMX12AA7D0N0-0 1.5
6.3
7
14.1
FAZ-B20/1N
MMX12AA9D6F0-0
MMX12AA9D6N0-0 2.2
8.7
9.6
15.8
FAZ-B32/1N
MMX32… frequency inverters
Three-phase mains connection (3 AC 230 V/240 V)
MMX32AA1D7F0-0
MMX32AA1D7N0-0 0.25
1.4
1.7
2.7
FAZ-B6/3
MMX32AA2D4F0-0
MMX32AA2D4N0-0 0.37
2
2.4
3.5
FAZ-B6/3
MMX32AA2D8F0-0
MMX32AA2D8N0-0 0.55
2.7
2.8
3.8
FAZ-B6/3
MMX32AA3D7F0-0
MMX32AA3D7N0-0 0.75
3.2
3.7
4.3
FAZ-B6/3
MMX32AA4D8F0-0
MMX32AA4D8N0-0 1.1
4.6
4.8
6.8
FAZ-B10/3
MMX32AA7D0F0-0
MMX32AA7D0N0-0 1.5
6.3
7
8.4
FAZ-B10/3
MMX32AA011F0-0
MMX32AA011N0-0
2.2
8.7
11
13.4
FAZ-B20/3
MMX34… frequency inverters
Three-phase mains connection (3 AC 400 V/480 V)
MMX34AA1D3F0-0
MMX34AA1D3N0-0 0.37
1.1
1.3
2.2
FAZ-B6/3
MMX34AA1D9F0-0
MMX34AA1D9N0-0 0.55
1.5
1.9
2.8
FAZ-B6/3
MMX34AA2D4F0-0
MMX34AA2D4N0-0 0.75
1.9
2.4
3.2
FAZ-B6/3
MMX34AA3D3F0-0
MMX34AA3D3N0-0 1.1
2.6
3.3
4
FAZ-B6/3
MMX34AA4D3F0-0
MMX34AA4D3N0-0 1.5
3.6
4.3
5.6
FAZ-B10/3
MMX34AA5D6F0-0
MMX34AA5D6N0-0 2.2
5
5.6
7.3
FAZ-B10/3
MMX34AA7D6F0-0
MMX34AA7D6N0-0 3
6.6
7.6
9.6
FAZ-B20/3
MMX34AA9D0F0-0
MMX34AA9D0N0-0 4
8.5
9
11.5
FAZ-B20/3
MMX34AA012F0-0
MMX34AA012N0-0
5.5
11.3
12
14.9
FAZ-B20/3
MMX34AA014F0-0
MMX34AA014N0-0
7.5
4)
15.2
4)
14
4)
18.7
FAZ-B25/3
Notes
All data apply at an ambient air temperature of up to +50 °C.
1)
The rated motor currents apply to normal internally and surface-cooled three-phase motors with 1500 rpm at 50 Hz or 1800 rpm at 60 Hz.
2)
If a frequency inverter is operated without mains chokes, current peaks can occur when mains power is applied. This can cause the FAZ-B…
to trip prematurely.
Remedy: fit a mains choke upstream or use an FAZ-C...
3)
Instead of PKM0, PKZM0 can also be used.
4)
Reduced rated operational data: Ambient air temperature up to +40 °C, operating frequency up to 4 kHz, mounting distance at sides (left and
right) > 10 mm
cable protection FAZ, PKM, PKZM￫chapter 7, 19
DIL mains contactor ￫chapter 5
Mains chokes DEX-LN…
￫Page 10/20
Radio interference suppression filters MMX-LZ…
￫Page 10/19
DEX-LM3-… motor chokes
￫Page 10/21
Sinusoidal filters SFB400/... please enquire
M-Max™
