Frequency inverters
Mains chokes, motor chokes
2010
CA08103002Z-EN
www.eaton.com10/37
Mainschokes,motorchokes
Part no.
Rated
operating
current
Inductance Maximum
heat
dissipation
Cu factor
1)
Voltage drop Connection
Bore hole
Pick-up
Terminal/connection lug
I
e
L
P
v
u
k
A
mH
W
%
mm
2
AWG
mm
Nm
Mains chokes, single-phase, rated operational voltage 1 AC 230 V, 50 Hz
DEX-LN1-006
5.8
5.05
9
0.09
4
4
20 - 10
–
0.8
DEX-LN1-009
8.6
3.41
11
0.11
4
4
20 - 10
–
0.8
DEX-LN1-013
13
2.25
12
0.18
4
4
20 - 10
–
0.8
DEX-LN1-018
18
1.63
17
0.27
4
4
20 - 10
–
0.8
DEX-LN1-024
24
1.22
20
0.33
4
4
20 - 10
–
0.8
Mains chokes, three-phase, rated operational voltage 3 AC 400 V, 50 Hz
DEX-LN3-004
3.9
7.51
17
0.25
4
4
20 - 10
–
0.8
DEX-LN3-006
6
4.9
19
0.34
4
4
20 - 10
–
0.8
DEX-LN3-010
10
2.94
33
0.45
4
4
20 - 10
–
0.8
DEX-LN3-016
16
1.84
44
0.53
4
4
20 - 10
–
0.8
DEX-LN3-025
25
1.18
57
0.90
4
4
20 - 10
–
0.8
DEX-LN3-040
40
0.64
59
0.91
2.5
10
20 - 6
–
1.5
DEX-LN3-050
50
0.37
58
1.08
2.5
Cu 15 x 2
7
3
DEX-LN3-060
60
0.31
60
1.51
2.5
Cu 15 x 2
7
3
DEX-LN3-080
80
0.23
86
1.67
2.5
Cu 20 x 3
9
6
DEX-LN3-100
100
0.18
101
1.68
2.5
Cu 20 x 3
9
6
DEX-LN3-120
120
0.15
100
2.26
2.5
Cu 25 x 5
11
10
DEX-LN3-160
160
0.11
140
2.35
2.5
Cu 25 x 5
11
10
DEX-LN3-200
200
0.09
154
3.81
2.5
Cu 25 x 5
11
10
DEX-LN3-250
250
0.07
155
4.26
0
Cu 40 x 5
14
15.5
DEX-LN3-300
300
0.06
169
4.28
2.5
Cu 40 x 5
14
15.5
Part no.
Rated
operating
current
Inductance Maximum
heat
dissipation
Max. heat dissipation
(
pulse frequency)
Cu factor
1)
Connection
Bore hole Pick-up
Terminal/connection lug
I
e
L
P
v
P
v
P
v
P
v
(3
kHz)
(5
kHz)
(12
kHz)
A
mH
W
W W W
mm
2
AWG
mm
Nm
Motor chokes, three-phase, rated operational voltage 3 AC 400 V, max. 200 Hz
DEX-LM3-005
5
2
24
12
14
24
0.29
4
20 - 10
–
0.8
DEX-LM3-008
8
4.1
54
32
46
54
1.09
4
20 - 10
–
0.8
DEX-LM3-011
11
3
71
45
66
71
1.23
4
20 - 10
–
0.8
DEX-LM3-016
16
1.5
78
50
75
78
0.88
4
20 - 10
–
0.8
DEX-LM3-035
35
1
116
75
114
116
2.30
4
20 - 10
–
0.8
DEX-LM3-050
50
0.6
168
110
157
168
3.60
10
20 - 6
–
1.5
DEX-LM3-063
63
0.5
193
130
190
193
3.01
Cu 15 x 2
7
3
DEX-LM3-080
80
0.5
206
132
206
206
5.88
Cu 20 x 3
9
6
DEX-LM3-100
100
0.45
294
177
279
294
10.10
Cu 20 x 3
9
6
DEX-LM3-150
150
0.35
424
293
418
424
8.22
Cu 25 x 5
11
10
DEX-LM3-180
180
0.3
498
418
439
498
14.75
Cu 25 x 5
11
10
DEX-LM3-220
220
0.2
517
344
512
517
11.37
Cu 40 x 5
14
15.5
DEX-LM3-260
260
0.15
520
358
526
520
11.10
Cu 40 x 5
14
15.5
Notes
1)
For material price surcharge ￫Chapter General information
DEX-LN..., DEX-LM3...
