Frequency inverters
HMX...
2010
CA08103002Z-EN
www.eaton.comPart no.
a
a1
b
b1
c
⌀ Weight
Frame size
mm mm mm mm mm mm kg
FS
HMX32AG011… 128
100
328
313
197
7
6
FS4
HMX32AG012… 128
100
328
313
197
7
6
FS4
HMX32AG018… 144
115
419
406
222
7
10
FS5
HMX32AG024… 144
115
419
406
222
7
10
FS5
HMX32AG031… 144
115
419
406
222
7
10
FS5
HMX32AG048… 195
148
557
541
236
9
20
FS6
HMX32AG062… 195
148
557
541
236
9
20
FS6
HMX32AG077… 234
660
266
37.5
FS7
HMX32AG088… 234
660
266
37.5
FS7
HMX32AG106… 234
660
266
37.5
FS7
HMX32AG143… 290
966
350
70
FS8
HMX32AG170… 290
966
350
70
FS8
HMX32AG208… 290
966
350
70
FS8
HMX32AG261… 480
1150
372
108
FS9
HMX32AG310… 480
1150
372
108
FS9
HMX32AG3D7… 128
100
328
313
197
7
6
FS4
HMX32AG4D8… 128
100
328
313
197
7
6
FS4
HMX32AG6D6… 128
100
328
313
197
7
6
FS4
HMX32AG8D0… 128
100
328
313
197
7
6
FS4
HMX34AG012… 128
100
328
313
197
7
6
FS4
HMX34AG016… 144
115
419
406
222
7
10
FS5
HMX34AG023… 144
115
419
406
222
7
10
FS5
HMX34AG031… 144
115
419
406
222
7
10
FS5
HMX34AG038… 195
148
557
541
236
9
20
FS6
HMX34AG046… 195
148
557
541
236
9
20
FS6
HMX34AG061… 195
148
557
541
236
9
20
FS6
HMX34AG077… 234
660
266
37.5
FS7
HMX34AG088… 234
660
266
37.5
FS7
HMX34AG106… 234
660
266
37.5
FS7
HMX34AG140… 290
966
350
70
FS8
HMX34AG170… 290
966
350
70
FS8
HMX34AG205… 290
966
350
70
FS8
HMX34AG261… 480
1150
372
108
FS9
HMX34AG310… 480
1150
372
108
FS9
HMX34AG3D4… 128
100
328
313
197
7
6
FS4
HMX34AG4D8… 128
100
328
313
197
7
6
FS4
HMX34AG5D6… 128
100
328
313
197
7
6
FS4
HMX34AG8D0… 128
100
328
313
197
7
6
FS4
HMX34AG9D6… 128
100
328
313
197
7
6
FS4
FS = frame size
