Fluorescent Lamps
>
TL5MASTER TL5 HO Secura G5
Wattage/
Colour
Code
Colour
Rende-
ring
Index
Colour
Tem-
pera-
ture
Lamp
Lumi-
nous
Flux
25°C
EL
Luminous
Flux EL
25°C,
Rated
Lum
E cacy
Rated
HF 35°C
Life to
10% fail
Preheat
EL,3h
Life to
50% fail
Preheat
EL,3h
Dim.
no.
Packing
type/
Packing
configu-
ration
National
Order Code
Ordering
number
8711500...
(R
a
)
(K)
(lm)
(lm)
(lm/W)
(h)
(h)
54W/840
82
4,000 4,450
4,450
93
21,000 30,000 A+ 1 UNP / 40 40
54840TL5SEC
952318
55
yes
80W/840
82
4,000 6,550
6,550
88
21,000 30,000 A 2 UNP / 40 40
80840TL5SEC
952356
55
yes
MASTER TL5 High Output 90 De Luxe
Product Description
•Low-pressure mercury discharge lamps with
a tubular 16 mm envelope
Product Benefits
•Allows system miniaturisation and maximum
luminaire design freedom, with lamp lengths
defined for easy fitting into ceiling module
systems
•Virtually constant lumen level with good
lumen maintenance
•Excellent colour rendering
Product Features
•40% thinner than existing TL-D lamps
•Highly e cient multi-band fluorescent
coating in combination with precoating and
high lamp load
•Specifically designed for operation with
electronic gear and well suited for dimming
•Maximum light output reached at approx.
35 °C in free-burning position if an electronic
ballast without additional electrode heating is
used
•Can be ignited from -15 to +50 °C
Application
•Where a high colour recognition is needed:
first aid and treatment rooms in hospitals,
printing rooms, jewellery manufacturing,
dentists, hairdressing, museums and shops
A
B
C
D
A B
C D
max. min. max. max. max.
549 553.7 556.1 563.2 17
MASTER TL5 HO 90 De Luxe G5
Wattage/
Colour Code
Colour
Rendering
Index
Colour
Tempera-
ture
Luminous
Flux EL
25°C, Rated
Lum
E cacy
Rated HF
35°C
Life to 10%
fail Preheat
EL,3h
Life to 50%
fail Preheat
EL,3h
Packing
type/
Packing
configu-
ration
National
Order Code
Ordering
number
8711500...
(R
a
)
(K)
(lm)
(lm/W)
(h)
(h)
24W/950
92
5,200
1,525
78
21,000
30,000 A 1SL / 20 20
24950
890641
00
yes
MASTER TL5 Circular
Product Description
•16 mm tube diameter circular fluorescent
lamps with a choice of various diameters
Product Benefits
•Slim 16 mm tube allows creation of
extremely flat luminaires
•Allows appealing circular designs
•High lamp e cacy
•Good colour rendering
•Temperature independent light output
•Higher average system e ciency
Product Features
•Perfect circular shape
•Highly e cient 3-band fluorescent coatin
•Specifically designed for operation with
electronic gear
•Can be ignited from -15 to +50 °C
•Amalgam technology
Application
•Brings the benefits of TL5 lighting to an even
wider range of attractive applications
•Suitable for a wide range of professional and
semi-professional applications
•Ideal for use in shops, o ces and public
areas with non-traditional lay-outs
•Amalgam lamps are limited suitable for
dimming applications
Philips Lamps and Lighting Electronic Catalogue 2014
