MASTER TL5 High Output EcoPlus
A
B
C
D
Dim. A B C D
no. max. min. max. max. max.
1 1449 1453.7 1456.1 1463.2 17
2 1149 1153.7 1156.1 1163.2 17
The ultimate step in energy saving with TL5
High Output
TL5 High Output EcoPlus lamp (tube dia-
meter 16 mm) provides extra energy savings
by simple lamp-for-lamp replacement of
TL5 HO Eco lamps, at the expense of slightly
reduced light output. No compromises
are made on the excellent TL5 lumen
maintenance, lifetime and colour rendering.
Application areas vary from o ces and
industry to schools and retail environments.
Product Benefits
•Up to 20% energy saving simply by changing
the lamp
•The same quality of light as from MASTER
TL5 HO lamps
•All benefits of regular TL5 lamps
Product Features
•High lamp e cacies up to 107 lm/W
•Up to 20% power reduction compared with
standard MASTER TL5 HO lamps and up to
10% compared with TL5 HO Eco lamps
Application
•All current non-dimmable TL5 HO indoor
applications, e. g. o ces, schools, super-
markets, industrial facilities with room
temperatures above 20 °C (which means
temperatures around the lamp of over
25-30 °C)
•Not recommended for use where there is a
strong air flow around the lamps
Warnings and Safety
-A reduction in energy consumption is only
achieved with current-controlled gear.
-The lamps operate perfectly with power-
controlled gear, but in that case the light
output can be up to 10% higher.
-TL5 HO EcoPlus is not designed for
dimming applications.
MASTER TL5 HO EcoPlus G5
Wattage/
Colour
Code
Colour
Rende-
ring
Index
Colour
Tem-
perature
Luminous
Flux EL
25°C, Rated
Lum
E cacy
Rated HF
35°C
Life to
10% fail
Preheat
EL,3h
Life to
50% fail
Preheat
EL,3h
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8718291...
(Ra) (K) (lm) (lm/W) (h) (h)
41W/840 82 4,000 4,250 107 21,000 30,000 A+ 1 UNP / 40 40 41840TL5ECO+ 66337900 yes
44W/840 82 4,000 3,900 102 21,000 30,000 A+ 2 UNP / 40 40 44840TL5ECO+ 66333100 yes
66W/840 82 4,000 5,700 97 21,000 30,000 A+ 1 UNP / 40 40 66840TL5ECO+ 66341600 yes
MASTER TL5 High Output Eco
A
B
C
D
Dim. A B C D
no. max. min. max. max. max.
1 549 553.7 556.1 563.2 17
2 1449 1453.7 1456.1 1463.2 17
3 1149 1153.7 1156.1 1163.2 17
The world’s most e cient and brightest
fluorescent lighting
This extremely e cient TL5 lamp (tube
diameter 16 mm) saves considerable energy
by simple lamp-for-lamp replacement.
The TL5 HO Eco lamp is optimized for
installations requiring high light output and
o ers excellent lumen maintenance and
colour rendering. Application areas vary from
o ces and industry to schools and retail
environments.
Product Benefits
•Up to 10% energy saving with simply
changing the lamp
•The same quality of light as compared with
MASTER TL5 HO lamps
•All benefits of regular TL5 lamps
Product Features
•High lamp e cacies up to 109 lm/W
•Up to 10% power reduction in comparison
with standard MASTER TL5 HO lamps
Environment
•Best environmental choice because of
highest available energy e ciency for
fluorescent lighting
•Less material, packaging, weight, transport
and recycling volume due to smallest
product dimensions
•This product range is RoHS compliant
•This product range is covered by WEEE
Application
•O ers very economic solutions for high-
ceiling lighting in shops, industry and
department stores
•The high luminous flux gives optimal results
in aesthetic pendants and furniture-mounted
luminaires in o ces, workshops, restaurants
and reception areas
Warnings and Safety
•A reduction in energy consumption is only
achieved with current-controlled gear.
•The lamps operate perfectly with power-
controlled gear, but in that case the light
output can be up to 10% higher.
