Lamps & Lighting Electronics Catalogue 2014

29 / 272

>
MASTER TL5 HE Secura
A
B
C
D
A B C D
max. min. max. max. max.
1149 1153.7 1156.1 1163.2 17
Shatterfree fluorescent lighting
This TL5 High E ciency Secura lamp (tube
diameter 16 mm) has a protective coating that
keeps glass and lamp components together in
the event of accidental breakage. The lamp is
easily identifiable by a blue ring at one end.
Application areas are all places where glass
shatters can disturb operations and can have
an impact on product and people safety, e.
g. the food and beverage industry. This lamp
is compliant with HACCP regulations and
supports HACCP certification.
Product Benefits
•Special protective coating around the lamp
prevents products from contamination in
case of accidental lamp breakage
•High temperature-resistance (up to 200 °C)
and no degradation under influence of
temperature or UV
•Making luminaires compliant with relevant
standards in the industry, such as HACCP,
ISO 22000 and IEC 61549
Product Features
•Protective coating around the lamp
•Fully compliant with IEC 61549 - Fragment
Retention Lamp Standard
•Compliant with relevant standards in
the food industry, such as HACCP and
ISO 22000
•Superior coating material (Teflon) with
high temperature resistance (up to 200 °C)
and no degradation under influence of
temperature or UV
•Single blue ring around one end for
identification
•Direct retrofit for all TL5 HE lamps
Environment
•Best environmental choice because of
highest energy e ciency
•This product is RoHS compliant
•This product is covered by WEEE
Application
•For use where contamination resulting from
lamp breakage must be prevented, e. g. in
food industry, suppliers to the food industry,
health care, pharmaceuticals, cleanrooms
etc.
•Suitable for use in environments with
increased risk of breakage, e. g. sports halls
MASTER TL5 HE Secura G5
Wattage/
Colour Code
Colour
Rendering
Index
Colour
Tempera-
ture
Luminous
Flux EL
25°C, Rated
Lum
E cacy
Rated HF
35°C
Life to 10%
fail
Preheat
EL,3h
Life to 50%
fail
Preheat
EL,3h
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8711500...
(Ra ) (K) (lm) (lm/W) (h) (h)
28W/840 82 4,000 2,625 104 19,000 24,000 A+ UNP / 40 40 28840TL5SEC 95215855 yes
MASTER TL5 High Output Secura
A
B
C
D
Dim. A B C D
no. max. min. max. max. max.
1 1149 1153.7 1156.1 1163.2 17
2 1449 1453.7 1456.1 1463.2 17
Shatterfree fluorescent lighting
This TL5 High Output Secura lamp (tube
diameter 16 mm) has a protective coating that
keeps glass and lamp components together in
the event of accidental breakage. The lamp is
easily identifiable by a blue ring at one end.
Application areas are all places where glass
shatters can disturb operations and can have
an impact on product and people safety, e.
g. the food and beverage industry. This lamp
is compliant with HACCP regulations and
supports HACCP certification.
Product Benefits
•Special protective coating around the lamp
prevents products from contamination in
case of accidental lamp breakage
•High temperature-resistance (up to 200 °C)
and no degradation under influence of
temperature or UV
•Making luminaires compliant with rel-
evant standards in the industry, such as
HACCP, ISO 22000 and IEC 61549
Product Features
•Protective coating around the lamp
•Fully compliant with IEC 61549 - Fragment
Retention Lamp Standard
•Superior coating material (Teflon) with
high temperature-resistance (up to 200 °C)
and no degradation under influence of
temperature or UV
•Single blue ring around one end for
identification
•Direct retrofit for all TL5 HO lamps
Environment
•Best environmental choice because of
highest energy e ciency
•This product is RoHS compliant
•This product is covered by WEEE
Application
•For use where contamination resulting from
lamp breakage must be prevented, e. g. in
food industry, suppliers to the food industry,
health care, pharmaceuticals, cleanrooms
etc.
•Suitable for use in environments with
increased risk of breakage, e. g. sports halls
Philips Lamps and Lighting Electronic Catalogue 2014 29
02
