Fluorescent Lamps
>
TL-DMASTER TL-D Eco
D
A
B
C
Dim.
A
B
C D
no.
max.
min.
max.
max.
max.
1 589.8 594.5 596.9 604.0 28
2 1199.4 1204.1 1206.5 1213.6 28
3 1500.0 1504.7 1507.1 1514.2 28
Product Description
•Low-pressure mercury discharge lamps with
a tubular 26 mm envelope
Product Benefits
•Simple lamp-for-lamp replacement for more
than 10% energy savings
•Makes lighting installations compliant
with latest indoor lighting standards
•Relatively high e cacy, both initially and
during lifetime, with high lumen maintenance
Product Features
•The only T8 fluorescent lamp that saves
more than 10% of energy in existing indoor
luminaires
•Can be directly retrofitted into existing
fluorescent fittings operating on conventional
EM or HF gear in indoor applications
•Uses the latest highly e cient phosphors
and special filling gas
•High-quality lighting with good colour
rendering (CRI
>
80)
•Light output comparable to other TL-D
Super 80 colours
•Lumen maintenance and lifetime the same as
other TL-D Super 80 colours
•Dimmable
Environment
•Allows easy switching to more energy-
conscious solutions
•Helps reduce CO
2
emissions and meet
climate change targets
•Philips Green Flagship label due to extremely
low mercury levels
•RoHS compliant
•Covered by WEEE
Application
•For use in indoor applications with room
temperatures above 20 °C (which implies
temperature around the lamp of over
25-35 °C)
•Primary focus on o ces, schools and
hospitals; secondary focus on retail, industry,
supermarkets
•Not recommended under the following
conditions:
- with air flow around the lamps
- in luminaires with active air handling
(lamp temperature will not be the required
25-35 °C, but room
temperature)
- in open luminaires/battens very close to
air conditioning outlets or cold air flows
- in space above freezers (temperature may
easily drop below 20 °C)
- in combination with VRUs (voltage
reduction units)
MASTER TL-D Eco G13
Wattage/
Colour
Code
Colour
Rende-
ring
Index
Colour
Tem-
perature
Luminous
Flux Lamp
EM 30°C
Luminous
Flux EM
25°C, Rated
Life to
10% fail
Preheat
EL,3h
Life to
50% fail
Preheat
EL,3h
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8711500...
(R
a
)
(K)
(lm)
(lm)
(h)
(h)
16W/840
85
4,000
1,300
1,175
17,000
20,000 A 1 1SL / 25 25
16840TLDECO
268617
40
yes
32W/830
85
3,000
3,000
2,650
17,000
20,000 A 2 1SL / 25 25
32830TLDECO
264589
40
yes
32W/840
85
4,000
3,000
2,650
17,000
20,000 A 2 1SL / 25 25
32840TLDECO
264626
40
yes
51W/830
85
3,000
4,800
4,550
17,000
20,000 A 3 1SL / 25 25
51830TLDECO
264664
40
yes
51W/840
85
4,000
4,800
4,550
17,000
20,000 A 3 1SL / 25 25
51840TLDECO
264701
40
yes
