Fluorescent Lamps
>
TL-DMASTER TL-D Power Saver Set
D
A
B
C
Dim.
A
B
C D
no.
max.
min.
max.
max.
max.
1 589.8 594.5 596.9 604.0 28
2 1199.4 1204.1 1206.5 1213.6 28
3 1500.0 1504.7 1507.1 1514.2 28
Simply 30% energy saving
The MASTER TL-D Power Saver Set is a
perfect solution for upgrading your existing
lighting installation with a special TL-D
lamp with an intelligent starter. It o ers
considerable energy savings while maintaining
the same lighting level and a better light
quality. The MASTER TL-D Power Saver Set
is easy to install, simply by changing the lamp
and the starter. The benefits are huge in all
current installations with TL-D lamps.
Product Benefits
•Significant energy saving while maintaining
light levels and improving light quality in
comparison with TL-D Standard colours
lamps (halophosphate)
•Higher colour rendering than TL-D Standard
colours lamps (halophosphate)
•Longer lifetime than TL-D Standard colours
lamps (halophosphate)
•Instant, smooth and flicker-free start-up of
the lamps
•Lamps are switched o directly at end-
of-life, preventing irritation (no flickering),
unnecessary electricity consumption and fire
risk
•Starter contains flame-retardant compon-
ents; UV-resistant canister ensures increased
safety and secure ignition
Product Features
•Up to 30% energy saving, while maintaining
the lighting level compared to a TL-D
Standard colours lamps (halophosphate), is
achieved by an intelligent electronic starter
in combination with the most e cient
fluorescent TL-D lamp
•Designed for operation on electromagnetic
gear only
•Full thermal safety monitoring which cuts o
defective or end-of-life lamps
•Instant flicker-free ignition (nom. 2.0
seconds)
•Can be ignited from -15 to +50 °C
•Product range is RoHS-compliant
•Product range is covered by WEEE
Application
•Suitable to replace TL-D Standard colours
lamps (halophosphate) in all existing TL-D
luminaires with electromagnetic gear
(220/240 V, 50 Hz). Use on 60 Hz and/or
110 V systems leads to non-functionality of
the system.
•Can also be used to replace MASTER TL-D
Super 80 lamps, but the light output of the
total installation will then be reduced by
approximately 20%.
MASTER TL-D Power Saver Set G13
Wattage/Colour
Code
Colour
Rendering
Index
Colour
Tempera-
ture
SystLum Flux
25°C,
Rated,@10kh
Life
System to
50%
failures
Dim. no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8727900...
(R
a
)
(K)
(lm)
(h)
12=18W/830
82
3,000
915
20,000 A 1
UNP / 25 25
18830TLDPSS
912081
00
yes
12=18W/830
82
3,000
915
20,000 A 1
1SL / 25 25
18830TLDPSS1X1
914962
00
yes
12=18W/840
82
4,000
915
20,000 A 1
1SL / 25 25
18840TLDPSS1X1
914986
00
yes
12=18W/840
82
4,000
915
20,000 A 1
UNP / 25 25
18840TLDPSS
912098
00
yes
12=18W/865
82
6,500
870
20,000 A 1
UNP / 25 25
18865TLDPSS
912104
00
yes
12=18W/865
82
6,500
870
20,000 A 1
1SL / 25 25
18865TLDPSS1X1
915006
00
yes
23=36W/830
82
3,000
2,100
20,000 A 2
1SL / 25 25
36830TLDPSS1X1
915020
00
yes
23=36W/830
82
3,000
2,100
20,000 A 2
UNP / 25 25
36830TLDPSS
912128
00
yes
23=36W/840
82
4,000
2,100
20,000 A 2
UNP / 25 25
36840TLDPSS
912135
00
yes
23=36W/840
82
4,000
2,100
20,000 A 2
1SL / 25 25
36840TLDPSS1X1
915044
00
yes
23=36W/865
82
6,500
1,900
20,000 A 2
1SL / 25 25
36865TLDPSS1X1
915068
00
yes
23=36W/865
82
6,500
1,900
20,000 A 2
UNP / 25 25
36865TLDPSS
912142
00
yes
37=58W/830
82
3,000
3,360
20,000 A 3
UNP / 25 25
58830TLDPSS
912159
00
yes
37=58W/830
82
3,000
3,360
20,000 A 3
1SL / 25 25
58830TLDPSS1X1
915082
00
yes
37=58W/840
82
4,000
3,360
20,000 A 3
1SL / 25 25
58840TLDPSS1X1
915105
00
yes
37=58W/865
82
6,500
3,215
20,000 A 3
1SL / 25 25
58865TLDPSS1X1
915129
00
yes
