MASTER TL-D Secura
D
A
B
C
Dim. A B C D
no. max. min. max. max. max.
1 589.8 594.5 596.9 604.0 28
2 1500.0 1504.7 1507.1 1514.2 28
Product Description
•Low-pressure mercury discharge lamps with
a tubular 26 mm envelope
Product Benefits
•Special protective coating in the lamp-,
prevents products from contamination in
case of accidental lamp breakage
•Easy identification in audit situations by blue
ring at one end
•Special fluorescent coating gives good colour
rendering
•Relatively high e cacy, both initially and
during lamp lifetime, with high lumen
maintenance
•Protects products from discolouring and loss
of taste by 90% lower UV emission
•Compliant with HACCP regulations and
supports HACCP certification
Product Features
•Protective coating around the entire lamp
•Blue ring around one end
•Direct retrofit for all Standard and Super /80
TL-D lamps operating on conventional or HF
gear
•Highly e cient 3-band fluorescent coating
in combination with New Generation
pre-coating technology
•Available in various colour designations
•Low mercury dose
•Recyclable at end-of-life, including the
protective lamp coating
•End-cap has green bottom plate to identify
lamp as recyclable
Environment
•Good environmental choice because of
lowest mercury content and lead-free
•This product is RoHS compliant
•This product is covered by WEEE
Application
•For use where contamination resulting
from lamp breakage must be prevented,
e. g. in food preparation, health care,
pharmaceuticals, cleanrooms etc.
•Suitable for use in environments with
increased risk of breakage, e. g. sports halls
•Suitable for use in environmens where UV
emission should be reduced (museums,
libraries, archives, food industry, fashion
shops, etc.)
Warnings and Safety
•Not suitable for closed luminaires (as
indicated by two blue rings)
•Recommended use in combination with
self-stopping lamp control system
MASTER TL-D Secura G13
Wattage/
Colour Code
Colour
Rendering
Index
Colour
Tempera-
ture
Luminous
Flux EM
25°C, Rated
Life to 10%
fail Preheat
EL,3h
Life to 50%
fail Preheat
EL,3h
Dim. no. Packing
type/
Packing
configu-
ration
National
Order Code
Ordering
number
8711500...
(Ra) (K) (lm) (h) (h)
18W/830 85 3,000 1,300 17,000 20,000 A 1 1SL / 25 25 18830SEC 640062 40 yes
58W/840 85 4,000 5,000 17,000 20,000 A 2 1SL / 25 25 58840BSEC 640185 40 yes
MASTER TL-D Reflex
D
A
B
C
Dim. A B C D
no. max. min. max. max. max.
1 589.8 594.5 596.9 604.0 28
2 1199.4 1204.1 1206.5 1213.6 28
3 1500.0 1504.7 1507.1 1514.2 28
Product Description
•Low-pressure mercury discharge lamps with
a tubular 26 mm envelope
Product Benefits
•Internal reflector directs the light where it is
needed
•Energy savings of 30-50% in non-reflector
luminaires without loss of light
•Internal reflector is not a ected by dust
accumulation (in contrast to normal TL-D
lamps)
•Relatively high e cacy, both initially and
during lifetime, with high lumen maintenance
Product Features
•Internal reflector directs the light via a 160°
‘window’
•Reflector directs 85% of the light down-
wards avoiding wasted light
•Direct retrofit for existing fluorescent fittings
operating on conventional or HF gear
•High-quality lighting with good colour
rendering (CRI > 80)
•Light output comparable to other TL-D
Super 80 colours
•Lumen maintenance and lifetime the same as
other TL-D Super 80 colours
•Dimmable
Environment
•30 – 50% energy savings make TL-D Reflex
an excellent environmental choice
•RoHS compliant
•Covered by WEEE
Application
•Luminaires without reflectors or with only
simple reflectors, mainly found in industry
and shops / supermarkets
