Fluorescent Lamps
>
TL-DMASTER TL-D Xtreme
D
A
B
C
Dim.
A
B
C D
no.
max.
min.
max.
max.
max.
1 589.8 594.5 596.9 604.0 28
2 1199.4 1204.1 1206.5 1213.6 28
3 1500.0 1504.7 1507.1 1514.2 28
Product Description
•Low-pressure mercury discharge lamp with a
tubular 26 mm envelope
Product Benefits
•Longer lifetime and less early failures lead
to less hassle and lower maintenance costs
and facilitate the change from spot to group
replacement
•Less waste and disposal cost at end-of-life
•Special fluorescent coating gives good colour
rendering
Product Features
•Significant reduction of early failures based
upon a new technology (patent pending)
•Extreme long and reliable lifetime
•Highly e cient 3-band fluorescent coating
in combination with New Generation
pre-coating technology
•Low mercury dose for a long-life lamp
(5 mg)
•Fully recyclable lamp technology
•End-cap has an x-shaped green bottom plate
to distinguish lamp from other fluorescent
lamps
Environment
•Good environmental choice because of long
reliable life (380% better than T8 standard),
low waste (only 1 lamp compared to 4 T8
standard), lowest mercury content and
lead-free
•This product is a Philips Green Flagship
•This product is RoHS compliant
•This product is covered by WEEE
Application
•Suitable for use in applications where
maintenance costs (high ceilings, di cult
to reach) and disruptive costs are high
(stopping of production process, closure
of tunnels), or where lamp failure is not
acceptable for e. g. safety reasons: tunnels,
process, food and petrochemical industries
Warnings and Safety
•To achieve published lifetimes for 100%
operation, do not dim below 30%
•When used on electromagnetic gear, it is
strongly recommended to apply only Philips
S10 or S10E starters (for 18 W types S2 or
S2E) to achieve the published lifetimes, and
to install new starters when relamping.
MASTER TL-D Xtreme G13
Wattage/
Colour Code
Colour
Rendering
Index
Colour
Tempera-
ture
Luminous
Flux EM
25°C, Rated
Life to 10%
fail Preheat
EL,3h
Life to 50%
fail Preheat
EL,3h
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8711500...
(R
a
)
(K)
(lm)
(h)
(h)
18W/840
85
4,000
1,350
66,000
79,000 A 1
1SL / 25 25
18840XTREME
544964
40
yes
18W/865
85
6,500
1,250
66,000
79,000 A 1
1SL / 25 25
18865XTREME
892751
40
yes
36W/840
85
4,000
3,250
66,000
79,000 A 2
1SL / 25 25
36840XTREME
558688
40
yes
36W/865
85
6,500
3,150
66,000
79,000 A 2
1SL / 25 25
36865XTREME
892775
40
yes
58W/840
85
4,000
5,150
66,000
79,000 A 3
1SL / 25 25
58840XTREME
558862
40
yes
58W/865
85
6,500
5,000
66,000
79,000 A 3
1SL / 25 25
58865XTREME
892799
40
yes
MASTER TL-D Xtreme Polar
D
A
B
C
Dim.
A
B
C D
no.
max.
min.
max.
max.
max.
1 1199.4 1204.1 1206.5 1213.6 40.5
2 1500.0 1504.7 1507.1 1514.2 40.5
Product Description
•Polar versions are regular MASTER TL-D
Xtra and Xtreme lamps inside a clear T12
tube
Product Benefits
•High lighting level in low ambient temper-
ature applications compared with other
fluorescent tubes
•Strong reduction in maintenance costs due
to high reliability and long lifetime
•Fully temperature-resistant in all conditions;
no temperature-related relamping problems
•Supports end-user sustainability programs
(low mercury level and low waste due to
long lifetime)
Product Features
•Improved lumen output in low ambient
temperatures
•The same reliable, long lifetime performance
as regular MASTER TL-D Xtra and Xtreme
•Robust lamp construction due to strong,
temperature-resistant assembly kit
•10 pcs. packaging
Environment
•Good environmental choice because of
highest energy e ciency in colder conditions
(
<
10 °C), long reliable life (380% better
than T8 standard), low waste (only 1 lamp
compared with 4 T8 standard), lowest
mercury content and lead-free
•This product is a Philips Green Flagship
•This product is RoHS compliant
•This product is covered by WEEE
Application
•Indoor: cold stores and other refrigerated
areas
•Outdoor: petrol stations, car parks, shipping
docks, petrochemical plants, sign lighting,
tunnels
Warnings and Safety
•To achieve published lifetimes for 100%
operation, do not dim below 30%
•When used on electromagnetic gear, it is
strongly recommended to apply only Philips
S10 or S10E starters (for 18 W types S2 or
S2E) to achieve the published lifetimes, and
to install new starters when relamping.
