Lamps & Lighting Electronics Catalogue 2014

43 / 272

>
D
A
B
C
Dim. A B C D
no. max. min. max. max. max.
1 589.8 594.5 596.9 604.0 28
2 1199.4 1204.1 1206.5 1213.6 28
3 1500.0 1504.7 1507.1 1514.2 28
MASTER TL-D 90 Graphica G13
Wattage/
Colour Code
Colour
Rendering
Index
Colour
Tempera-
ture
Luminous
Flux EM
25°C, Rated
Life to 10%
fail Preheat
EL,3h
Life to 50%
fail Preheat
EL,3h
Dim. no. Packing
type/
Packing
configu-
ration
National
Order Code
Ordering
number
8711500...
(Ra) (K) (lm) (h) (h)
18W/950 97 5,300 950 17,000 20,000 B 1 1SL / 10 10 18950GP 888501 25 yes
18W/965 98 6,500 930 17,000 20,000 B 1 1SL / 10 10 18965GP 888525 25 yes
36W/950 97 5,300 2,340 17,000 20,000 B 2 1SL / 10 10 36950GP 888648 25 yes
36W/965 98 6,500 2,100 17,000 20,000 B 2 1SL / 10 10 36965GP 888365 25 yes
58W/950 97 5,300 3,670 17,000 20,000 B 3 1SL / 10 10 58950GP 888754 25 yes
58W/965 98 6,500 3,350 17,000 20,000 B 3 1SL / 10 10 58965GP 888778 25 yes
TL-D Blacklight Blue
For reliable unveiling of secrets
TL-D/8 Blacklight Blue lamps are low-
pressure mercury-vapor fluorescent lamps.
They have an inner envelope coated with a
fluorescent powder that emits long-wave UV
radiation to excite luminescence.
Product Benefits
•Quick detection of UV-reflecting materials
•Creates special lighting atmospheres and
e ects
Product Features
•Straight outer envelope
Application
•Detection and analysis in the textile and
chemical industries
•Banking and forensic science
•Special e ects in night clubs, discos and
theatres, and sign lighting
System
•’TL’D/8 lamps operate on AC mains supply
via a ballast and a starter
D
A
B
C
Dim. A B C D
no. max. min. max. max. max.
1 589.8 594.5 596.9 604.0 28
2 1199.4 1204.1 1206.5 1213.6 28
TL-D G13
Wattage/Colour Code Life to 50% failures
EM
Dim. no. Packing type/
Packing
configuration
National Order Code Ordering number
8711500...
(h)
18W/108 13,000 1 1SL / 25 25 1808 95111340 yes
36W/108 15,000 2 1SL / 25 25 3608 95115140 yes
Philips Lamps and Lighting Electronic Catalogue 2014 43
