Lamps & Lighting Electronics Catalogue 2014

36 / 272

>
MASTER TL-D Reflex G13
Wattage/
Colour Code
Colour
Rendering
Index
Colour
Tempera-
ture
Luminous
Flux EM
25°C, Rated
Life to 10%
fail Preheat
EL,3h
Life to 50%
fail Preheat
EL,3h
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8711500...
(Ra) (K) (lm) (h) (h)
18W/830 85 3,000 1,350 17,000 20,000 A 1 1SL / 25 25 18830R 636447 40 yes
18W/840 85 4,000 1,350 17,000 20,000 A 1 1SL / 25 25 18840R 636478 40 yes
18W/865 85 6,500 1,300 17,000 20,000 A 1 1SL / 25 25 18865RFECO 260291 40 yes
36W/840 85 4,000 3,350 17,000 20,000 A 2 1SL / 25 25 36840R 559531 40 yes
58W/840 85 4,000 5,240 17,000 20,000 A 3 1SL / 25 25 58840R 559623 40 yes
58W/865 85 6,500 5,000 17,000 20,000 A 3 1SL / 25 25 58865RFECO 260338 40 yes
MASTER TL-D HF Super 80
Product Description
•Low-pressure mercury discharge lamps with
a tubular 26 mm envelope and argon gas
filling
Product Benefits
•Relatively high e cacy, both initially and
during lamp lifetime, with high lumen
maintenance
•Good colour rendering
•Creates atmospheres from warm white to
cool daylight
Product Features
•Highly e cient 3-band fluorescent coating
in combination with New Generation
pre-coating technology
•High initial lumen output
•Available in varying colour designations
•Low mercury dose
•MASTER TL-D lamps are fully recyclable
•End-cap has green bottom plate to identify
lamp as recyclable
Application
•Suitable for use in a wide range of luminaires
for TL-D fluorescent lamps for ’human’
applications such as schools, o ces, shops,
factory halls etc.
Warnings and Safety
•Special electronic gear must be used
D
A
B
C
Dim. A B C D
no. max. min. max. max. max.
1 589.8 594.5 596.9 604.0 28
2 1199.4 1204.1 1206.5 1213.6 28
3 1500.0 1504.7 1507.1 1514.2 28
MASTER TL-D HF Super 80 G13
Wattage/
Colour Code
Colour
Rendering
Index
Colour
Tempera-
ture
Luminous
Flux EL 25°C,
Rated
Life to 10%
fail Preheat
EL,3h
Life to 50%
fail Preheat
EL,3h
Dim. no. Packing
type/
Packing
configu-
ration
National
Order Code
Ordering
number
8711500...
(Ra) (K) (lm) (h) (h)
16W/830 85 3,000 1,400 17,000 20,000 A 1 1SL / 25 25 16830 631442 40 yes
16W/840 85 4,000 1,400 17,000 20,000 A 1 1SL / 25 25 16840 631473 40 yes
32W/840 85 4,000 3,200 17,000 20,000 A+ 2 1SL / 25 25 32840 631534 40 yes
50W/840 85 4,000 5,000 17,000 20,000 A+ 3 1SL / 25 25 50840 631596 40 yes
Philips Lamps and Lighting Electronic Catalogue 2014 36
