MASTER TL5 High E ciency Xtra Eco
A
B
C
D
Dim. A B C D
no. max. min. max. max. max.
1 549 553.7 556.1 563.2 17
2 1149 1153.7 1156.1 1163.2 17
3 1449 1453.7 1456.1 1463.2 17
The ideal combination of extra-long life and
highest e ciency
TL5 High E ciency Xtra Eco lamp (tube dia-
meter 16 mm) provides the ideal combination
of extra-long life and extra energy savings via
simple lamp-for-lamp replacement of TL5 HE
lamps, without any compromise on the high
lighting quality.
Product Benefits
•The longer product lifetime lowers mainten-
ance costs and facilitates the change from
spot to group replacement, while at the
same time reducing waste and disposal cost.
•Up to 10% energy saving
•The same quality of light as from MASTER
TL5 HE lamps
Product Features
•High lamp e cacies up to 114 lm/W
•Up to 10% power reduction and double the
lamp life compared to standard MASTER
TL5 HE
Application
•All current TL5 HE applications, e. g. o ces,
schools, supermarkets, industry
Warnings and Safety
•A reduction in energy consumption is only
achieved with current-controlled gear.
•The lamps operate perfectly with power-
controlled gear, but in that case the light
output can be up to 10% higher.
•To achieve lifetimes as published for 100%
operation, dimming below 30% should not
be applied.
MASTER TL5 HE Xtra Eco G5
Wattage/
Colour
Code
Colour
Rende-
ring
Index
Colour
Tem-
perature
Luminous
Flux EL
25°C,
Rated
Lum
E cacy
Rated HF
35°C
Life to
10% fail
Preheat
EL,3h
Life to
50% fail
Preheat
EL,3h
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8718291...
(Ra ) (K) (lm) (lm/W) (h) (h)
13W/840 82 4,000 1,150 104 30,000 45,000 A 1 1SL / 40 40 13840TL5ECOXTRA 66942500 yes
25W/830 82 3,000 2,600 112 30,000 45,000 A 2 1SL / 40 40 25830TL5ECOXTRA 66944900 yes
25W/840 82 4,000 2,600 112 30,000 45,000 A 2 1SL / 40 40 25840TL5ECOXTRA 66946300 yes
32W/840 82 4,000 3,250 111 30,000 45,000 A 3 1SL / 40 40 32840TL5ECOXTRA 66950000 yes
MASTER TL5 High E ciency Eco
A
B
C
D
Dim. A B C D
no. max. min. max. max. max.
1 549 553.7 556.1 563.2 17
2 849 853.7 856.1 863.2 17
3 1149 1153.7 1156.1 1163.2 17
4 1449 1453.7 1456.1 1463.2 17
The world’s most e cient fluorescent lighting
This extremely e cient TL5 lamp (tube
diameter 16 mm) saves considerable energy
by simple lamp-for-lamp replacement.
The TL5 HE Eco lamp o ers excellent
lumen maintenance and colour rendering.
Application areas vary from o ces and
industry to schools and retail environments.
Product Benefits
•Up to 10% energy saving with simply
changing the lamp
•The same quality of light as compared with
MASTER TL5 HE lamps
•All benefits of regular TL5 lamps
Product Features
•High lamp e cacies up to 114 lm/W
•Up to 10% power reduction in comparison
with standard MASTER TL5 HE lamps
•Fluorescent Super 80 light quality
Environment
•Best environmental choice because of
highest available energy e ciency for
fluorescent lighting
•Less material, packaging, weight, transport
and recycling volume due to smallest
product dimensions
•This product range is RoHS compliant
•This product range is covered by WEEE
Application
•Ideally suited for recessed, surface-mounted
and suspended luminaires e. g. in o ces,
shops, schools, public buildings and industry
(low ceiling), wherever high-quality,
energy-e cient lighting is required
Warnings and Safety
•A reduction in energy consumption is only
achieved with current-controlled gear.
•The lamps operate perfectly with power-
controlled gear, but in that case the light
output can be up to 10% higher.
