Analog input modules
Type of input
Input signal
range
Resolution Connection
No. of
channels
Reference
Weight
kg
High level analog with
common point
± 10 V,
0...10
V,
0...5
V,
1...5
V,
0...20
mA,
4...20
mA
16
bits
1
x 25-way
SUB-D
connector
4
high-speed
channels
TSX AEY 420
0.330
Low level analog isolated
± 10 V,
0...10
V,
0...5
V,
1...5
V,
± 5 V,
0...20
mA,
4...20
mA,
- 13...
+ 63 mV,
0...400
0...3850
,
temp. probe,
thermocouple
16
bits
Screw terminal
block
(1)
4
channels
TSX AEY 414
0.320
High level analog with
common point
± 10 V,
0...10
V,
0...5
V,
1...5
V,
0...20
mA,
4...20
mA
12
bits
1
x 25-way
SUB-D
connector
8
channels
TSX AEY 800
0.310
2
x 25-way
SUB-D
connectors
16
channels
TSX AEY 1600
0.340
High level analog isolated
± 10 V,
0...10
V,
0...5
V,
1...5
V
0...20
mA
4...20
mA
16
bits
1
x 25-way
SUB-D
connector
8
channels
TSX AEY 810
0.330
Thermocouple
± 63 mV,
(
B, E, J, K, L, N,
R, S, T, U)
16
bits
2
x 25-way
SUB-D
connectors
16
channels
TSX AEY 1614
0.350
Analog output modules
Type of output
Output signal
range
Resolution Connection
No. of
channels
Reference
(1)
Weight
kg
Analog isolated
± 10 V,
0...20
mA,
4...20
mA
11
bits
+ sign
Screw terminal
block
(2)
4
channels
TSX ASY 410
0.350
Analog with
common point
± 10 V,
0...20
mA,
4...20
mA
13
bits
+ sign
1
x 25-way
SUB-D
connector
8
channels
(2)
TSX ASY 800
–
(1)
TSX BLY 01
removable screw terminal block not supplied. To be ordered separately.
(2)
The number of
TSX ASY 800
modules is limited to 1 per rack with single format power supply, and 2 per rack with double
format power supply (when this supplies the 24
c
VR voltage required by the outputs).
