Selection guide
Applications
Analogue inputs
Type of I/O
Inputs isolated between low
level channels, thermocouple,
temperature probe
Thermocouple inputs
High level inputs with
common point
Type
Multirange
Multirange
Voltage/current
Range
Voltage
± 10 V, ± 5 V, 0…10 V,
0…5
V, 1…5 V
- 80…
+ 80 mV
± 10 V, 0…10 V, 0…5 V,
1…5
V
Current
4…20
mA, 0…20 mA
external shunt supplied
–
0…20
mA, 4…20 mA
Thermocouple,
Temperature probe
B, E, J, K, L, N, R, S, T, U
thermocouples 2 or 4-wire
Pt 100, Pt 1000, Ni 1000
temperature probes
B, E, J, K, L, N, R, S, T, U
thermocouples
–
Modularity
4
channels
16
channels
8
channels
Isolation
Between channels:
2830
V
a
rms
Between bus and channels:
1780
V
a
rms
Between channels and earth:
1780
V
a
rms
Between channels:
± 100 V
c
Between bus and channels:
1000
V
a
rms
Between channels and earth:
1000
V
a
rms
Between channels:
common point
Between bus and channels:
1000
V
a
rms
Between channels and earth:
1000
V
a
rms
Read time
550
ms
1120
ms (normal scan)
70
ms/channel used
(
fast scan)
27
ms (normal scan)
3
ms/channel used
(
fast scan)
Response time
Configurable filtering
0
to 68.5 s
User-definable filtering
0.04
Te…0.012 Te
(
Te: module scan time)
User-definable filtering
0
to 3.44 s
Resolution
16
bits
16
bits
12
bits
Connection
20-
way screw terminal block:
TSX BLY 01
Two 25-way SUB-D
connectors
One 25-way SUB-D
connector
or two Modicon Telefast
ABE 7CPA12 sub-bases
or one Modicon Telefast
ABE 7CPA02/03 sub-base
Standards
Compatible with sensors acc. to standards IEC/EN 60584-1/2/3
(
Thermocouples) and IEC/EN 60751 (Pt 100 temp. probes)
PLC: IEC/EN 61131-2
PLC: IEC/EN 61131-2
Consumption
See page 9/6
Type of module
TSX AEY 414
TSX AEY 1614
TSX AEY 800
Pages
3/16
Modicon Premium automation
platform
