Modicon Premium automation
platform
0
Discrete I/O modules
References
(
continued)
Discrete output modules
Type of
current
Output
voltage
Connection
(1)
IEC/EN
61131-2
conformity
Modularity
(
no. of
channels)
Reference
Weight
kg
c
transistor
24
V/0.5 A
(
pos. logic)
Screw
terminal block
Yes
8
protected
outputs
TSX DSY 08T2
0.320
24
V/2 A
(
pos. logic)
Screw
terminal block
Yes
8
protected
outputs
TSX DSY 08T22
0.410
24
V/0.5 A
(
pos. logic)
Screw
terminal block
Yes
16
protected
outputs
TSX DSY 16T2
0.340
48
V/1 A
(
pos. logic)
Screw
terminal block
Yes
8
protected
outputs
TSX DSY 08T31
0.320
48
V/0.25 A
(
pos. logic)
Screw
terminal block
Yes
16
protected
outputs
TSX DSY 16T3
0.340
24
V 0.1A
per channel
(
pos. logic)
HE 10
connector
Yes
32
protected
outputs
TSX DSY 32T2K
0.300
64
protected
outputs
TSX DSY 64T2K
0.360
c
or
a
relay
24
V/3 A
c
,
24
to 240 V/
3
A
a
Screw
terminal block
Yes
8
non-
protected
outputs
TSX DSY 08R5
0.330
16
non-
protected
outputs
TSX DSY 16R5
0.380
24
to 48 V/
5
A
c
, 24
to
240
V/5 A
a
Screw
terminal block
Yes
8
protected
outputs
TSX DSY 08R5A
0.420
c
relay
24...120
V
5
A
Screw
terminal block
Yes
8
protected
outputs
TSX DSY 08R4D
0.370
a
triac
24...120
V
1
A per
channel
Screw
terminal block
Yes
16
non-
protected
outputs
TSX DSY 16S4
0.380
48...240
V
1
A per
channel
Screw
terminal block
Yes
16
protected
outputs
TSX DSY 16S5
0.310
48...240
V
2
A per
channel
Screw
terminal block
Yes
8
protected
outputs
TSX DSY 08S5
0.340
Discrete I/O modules
Number
of I/O
Connection
(1)
No. and type
of inputs
No. and
type of
outputs
IEC/EN
611312
conformity
Reference
Weight
kg
28
HE 10
connector
16
fast
(
pos. logic)
(2)
12,
transistor
24
V/0,5 A
c
protected
Input, type 1
Output, yes
TSX DMY 28FK
0.320
12,
reflex
or time-
delayed
24
V/0.5 A
c
protected
Inputs,
type 1
TSX DMY 28RFK
0.350
(1)
By connector: module supplied with cover. By screw terminal block: terminal block
TSX BLY 01
to be ordered separately.
(2)
Module with fast isolated inputs (filtering from 0.1 to 7.5 ms) which can activate the
event-triggered task.
TSX DMY 28FK/28RFK
TSX DSY 64T2K
Principle:
page 3/6
Description:
page 3/7
Functions:
pages 3/8 …
