Type of splitter box and module

Monobloc IP 67 I/O splitter boxes

Modicon ETB

Available buses and

networks

Ethernet Modbus TCP/IP

EtherNet/IP

Max. number per connection point

Discrete I/O

Modularity

Splitter box with 16 configurable I/O, 16 I, 12 I + 4 O, or 8 I +8 O

Input voltage

24

V

c

Output voltage

24

V

c

Analog I/O

–

Application-specific I/O

–

–

I/O connection

M12 connectors

Type of housing

Plastic

Type of module

ETB 1E

ppp

Pages

Please consult the catalogue pages on our website
