Compatibility
Installation system
3
TeSys Quickfit for motor starter
components
TeSys Quickfit, compatibility with PLC I/O and distributed I/O
Automation platforms
Parallel wiring module
Modicon STB
parallel interface module
Type
Modularity of
connection to
the PLC
Compatible I/O
modules
Splitter box
-
For 8 TeSys model U motor starters (16 PLC
inputs and 8 PLC outputs)
- 8
RJ45 connectors, motor starter side
- 2
HE 10 connectors, PLC side
Module
-
For 4 TeSys model U motor starters
- 4
RJ45 connectors, motor starter side
LU9 G02
STB EPI 2145
Modicon TSX Micro platform
16
inputs
+ 12 outputs
TSX DMZ 28DTK
8
motor starters max.: 1 splitter box
2
x 16 inputs
+ 2 x 16 outputs
TSX DMZ 64DTK
16
motor starters max.: 2 splitter boxes
Modicon Premium platform
16
inputs
+ 12 outputs
TSX DMY 28FK
8
motor starters max.: 1 splitter box
2
x 16 inputs
+ 2 x 16 outputs
TSX DEY 32D2K
16
motor starters max.: 2 splitter boxes
TSX DSY32T2K
4
x 16 inputs
+ 2 x 16 outputs
TSX DEY 64D2K
32
motor starters max.: 4 splitter boxes
TSX DSY32T2K
Modicon Quantum platform
2
x 16 inputs
+ 2 x 16 outputs
140
DDI 353 00,
140
DDI 853 00
16
motor starters max.: 2 splitter boxes
140
DD0 353 10
6
x 16 inputs
+ 6 x 16 outputs
140
DDI 364 00
48
motor starters max.: 6 splitter boxes
140
DD0 364 00
Modicon STB distributed I/O
16
inputs
+ 8 outputs
STB EPI 1145
4
motor starters max.: 1 parallel interface
module
Presentation:
page 3/20
