Modicon Premiumautomation
platform
0
Standards, certifications and environmental
conditions
Standards and certifications
Modicon Premium PLCs have been developed to comply with the main national and
international standards relating to electronic equipment for industrial automation
systems.
b
Requirements specific to PLCs: functional characteristics, immunity, resistance,
safety, etc.: IEC/EN 61131-2, CSA 22.2 No. 142, UL 508
b
Merchant navy requirements from the main international bodies: ABS, BV, DNV,
GL, LR, RINA, RMRS, etc.
b
Compliance with European Directives:
v
Low Voltage Directive No. 2006/95/EC
v
Electromagnetic Compatibility Directive No. 2004/108/EC
b
Electrical characteristics and self-extinguishing capacity of insulating materials:
UL 746C, UL 94
b
Hazardous areas: CSA 22.2 No. 213, Class I, Division 2, groups A, B, C and D
Characteristics
Operating conditions and requirements relating to the environment
Temperature
Operation
°C
0...
+ 60 (IEC/EN 61131-2, + 5...+ 55)
(1)
0...
+ 70 with TSX FAN modules
(1)
Storage
°C
-25...
+ 70 (according to IEC/EN 61131-2)
Relative humidity
Operation
%
10…95
non-condensing
Storage
%
5…95
non-condensing (according to IEC/EN 61131-2)
Altitude
m
0…2000
Supply voltage
TSX PSY
p
610
TSX PSY 5520
TSX PSY 2600
TSX PSY
p
500
Nominal voltage
V
24
c
48
c
100...240
a
100...120
a
200...240
a
Voltage limits
19..30
c
19..60
c
90...264
a
140/190...264
a
Nominal frequency
Hz
–
–
50/60
50/60
Frequency range
Hz
–
–
47/63
47/63
Protective treatment of Modicon Premium PLCs
Modicon Premium/Atrium PLCs comply with “TC” treatment requirements
(
Treatment for all Climates)
.
For installations in industrial production workshops or environments corresponding
to “TH”
(
Treatment for Hot and humid environments)
,
PLCs must be housed in
enclosures providing at least IP 54 protection as specified by standard IEC/EN 60529,
or an equivalent level of protection according to NEMA 250.
Modicon Premium/Atrium PLCs themselves offer
IP 20 degree of protection
(2)
.
They can therefore be installed without an enclosure in reserved access areas that
do not exceed
pollution level 2
(
control room with no dust-producing machinery or
activity). Pollution level 2 does not take account of more severe environments, such
as those where the air is polluted with dust, fumes, corrosive or radioactive particles,
vapours or salts, moulds, insects, etc.
Treatment for corrosive environments:
Some processors, power supplies,
modules on Bus X and racks can be supplied with protective coating in order to
withstand corrosive environments (see page 9/2).
(1)
TSX P57 0244/104
/
154
M
and
TSX P57 454
/
4634
/
554
/
5634
/
6634
M
processors: 0…+ 57°C
(
or 0…+ 67°C with
TSX FAN
pp
P
fan modules) when certain I/O modules are mounted in the
slot next to the above-mentioned processors.
(2)
If a slot is not occupied by a module, it must be fitted with a protective cover
TSX RKA 02
.
