Modicon Premiumautomation
platform
0
Standards, certifications and environmental
conditions
Environmental tests
(
continued)
Environmental tests
(
continued)
Description of test
Standards
Levels
Immunity to climatic variations
Dry heat
IEC/EN 60068-2-2 Bd
60
°C for 16 hours (D.O); 40°C for 16 hours (D.C)
Cold
IEC/EN 60068-2-1 Ad
0
°C for 16 hours
Damp heat, steady state
IEC/EN 60068-2-3 Ca
60
°C with 93% relative humidity/96 hours (D.O);
40
°C with 93...95% relative humidity/96 hours (D.C)
Damp heat, cyclic
IEC/EN 60068-2-3 Db
[55
°C (D.O)/40°C (D.O)] - 25°C with 93...95% relative humidity; 2 cycles: 12 hours/12 hours
Change of temperature, cyclic
IEC/EN 60068-2-14 Nb
0...60
°C/5 cycles: 6 hours/6 hours (D.O)
(1)
0...40
°C/5 cycles: 6 hours/6 hours (D.C)
Temperature rise
IEC/EN 61131-2/UL 508
CSA 22-2 No. 142
Ambient temperature: 60°C
Resistance to climatic variations
Dry heat, non-operating
IEC/EN 60068-2-2 Bb
70
°C for 96 hours
Cold, non-operating
IEC/EN 60068-2-1 Ab
- 25
°C for 96 hours
Damp heat, non-operating
IEC/EN 60068-2-30 dB 25...60°C with 93...95% relative humidity; 2 cycles: 12 hours/12 hours
Thermal shock, non-operating
IEC/EN 60068-2-14 Na
- 25...70
°C; 2 cycles: 3 hours/3 hours
D.O: Device Open (device to be incorporated in an enclosure)
D.C: Device Closed (device which can be installed without an enclosure) (see
(1)
on page 9/8)
(1)
TSX P57 0244/104/154M
and
TSX P57 454/4634/554/5634/6634M
processors: 0…+ 57°C
(
or 0…+ 67°C with
TSX FAN
pp
P
fan modules) when certain I/O modules are mounted in the
slot next to the above-mentioned processors.
