Environmental tests
Description of test
Standards
Levels
Immunity to Low Frequency (LF) interference
(
e
)
(1)
Voltage and frequency variation
IEC/EN 61131-2
0.85
Un/0.95 Fn for 30 min; 1.15 Un/1.05 Fn for 30 min;
0.8
Un/0.9 Fn for 5 s; 1.2 Un/1.1 Fn for 5 s
DC voltage variation
IEC/EN 61131-1
0.85
Un...1.2 Un for 30 min with 5% ripple (peak values)
Third harmonic
IEC/EN 61131-2
10%
Un; 0°/5 min...180°/5 min
Short interruptions
IEC/EN 61131-2
10
ms with
a
power supply; 1 ms with
c
power supply
Voltage dips and pick-ups
IEC/EN 61131-2
Un-0-Un; Un for 60 s; 3 separate cycles of 10 s
Un-0-Un; Un for 5 s; 3 separate cycles of 1 to 5 s
Un-0.9 Udl; Un for 60 s; 3 separate cycles of 1 to 5 s
Un: nominal voltage
Fn: nominal frequency
Udl: undervoltage detection level
Description of test
Standards
Levels
Immunity to High Frequency (HF) interference
(
e
)
(1)
Damped oscillatory wave
IEC/EN 61000-4-12
a
/
c
power supply: 1kV in serial mode
Discrete I/O
u
24
V: 1 kV in serial mode
Electrical fast transients/Bursts
IEC/EN 61000-4-4
a
/
c
power supply: 2 kV in wired mode/common mode
Discrete I/O > 48 V: 2 kV in common mode; other ports: 1 kV in common mode
Hybrid surge
IEC/EN 61000-4-5
a
/
c
power supply: 2 kV in wired mode/1 kV in serial mode
a
discrete I/O: 2 kV in wired mode/1 kV in serial mode;
c
discrete I/O: 2 kV in wired mode/
0.5
kV in serial mode; shielded cable: 1 kV in common mode
Electrostatic discharge
IEC/EN 61000-4-2
6
kV contact, 8 kV air
Radiated electromagnetic field
IEC/EN 61000-4-3
10
V/m; 80 MHz...2 GHz
Sinusoidal amplitude modulation 80%/1 kHz
Conducted disturbances, induced
by radio-frequency fields
IEC/EN 61000-4-6
10
V/0.15 MHz...80 MHz
Sinusoidal amplitude modulation 80%/1 kHz
Electromagnetic emissions
(
e
)
(1) (2)
Interference voltage
IEC/EN 61000-6-4
Class A
150
kHz...500 kHz quasi-peak 79 dB(μV); average 66 dB(μV)
500
kHz...30 MHz quasi-peak 73 dB(μV); average 60 dB(μV)
IACS E10
General power supply distribution area
Quasi-peak limit values in dB (μV):
b
10
kHz…150 kHz: 96 to 50 dB (μV)
b
150
kHz…350 kHz: 60 to 50 dB (μV)
b
350
kHz …30 MHz: 50 dB (μV)
Field interference
(3)
IEC/EN 61000-6-4
Class A, measurement at 10 m
30
MHz...230 MHz quasi-peak 40 dB (μV); 230 MHz...1 GHz quasi-peak 47 dB (μV)
IACS E10
(4)
General power supply distribution area
Quasi-peak limit values in dB (μV), measurements at 3 m:
b
150
kHz…30 MHz: 80 to 50 dB (μV)
b
30
MHz…100 MHz: 60 to 54 dB (μV)
b
100
MHz...156 MHz: 54 dB (μV)
b
156
MHz...165 MHz: 24 dB (μV)
b
165
kHz …2 GHz: 54 dB (μV)
(
e
):
Tests required by the
e
European Directives and based on standard IEC/EN 61131-2.
(1)
Devices must be installed and wired in accordance with the instructions in the “Grounding and
Electromagnetic Compatibility of PLC Systems” manual, available in pdf format on the
CD-ROM supplied with Unity Pro or PL7 software packages or included on DVD reference
UNY USE 909 CD M
(
see page 6/20).
(2)
These tests are carried out with no enclosure, with the devices
fixed on a metal grid
and
wired in accordance with the recommendations in the “Grounding and Electromagnetic
Compatibility of PLC Systems” manual.
(3)
In cases where the limits of electromagnetic emissions between 30 MHz and 1 GHz need
to be monitored, it is recommended that
TSX RKY 6EX/8EX
racks be used instead of
TSX RKY 6/8
racks.
(4)
The devices must be installed in a metal enclosure.
