392 / 413
9/4
Power supply modules
Supply voltage
Available power
Reference
Weight
kg
5
V
c
24
VR
c
24
VC
c
Total
24
V
c
non-isolated
15
W 15 W –
30
W
(1)
TSX PSY 1610MC
0.540
35
W 19 W –
50
W
TSX PSY 3610MC
0.780
24…48
V
c
isolated
35
W 19 W –
50
W
TSX PSY 5520MC
0.980
110…240
V
a
25
W 15 W 12 W 26 W
(1)
TSX PSY 2600MC
0.510
110…120
V
a
and 200…240 V
a
35
W 19 W 19 W 50 W
TSX PSY 5500MC
0.620
75
W –
38
W SELV 77 W
TSX PSY 8500MC
0.740
For
accessories and fan modules
,
see page 2/4 and 2/5.
(
1)
Single format module. The other power supply modules are double format.
Discrete I/O modules
Type
Voltage, logic
Connection by
Description
Reference
Weight
kg
c
inputs
24
V, positive logic Screw terminal block 8 isolated inputs, type 2
TSX DEY 08D2C
0.300
16
isolated inputs, type 2
TSX DEY 16D2C
0.300
48
V, positive logic Screw terminal block 16 isolated inputs, type 2
TSX DEY 16D3C
0.300
24
V, positive logic HE 10 connector
16
isolated fast inputs, type 1
TSX DEY 16FKC
0.300
2
x HE 10 connectors 32 isolated inputs, type 1
TSX DEY 32D2KC
0.300
4
x HE 10 connectors 64 isolated inputs, type 1
TSX DEY 64D2KC
0.370
24
V, negative logic Screw terminal block 16 isolated inputs, type 2
TSX DEY 16A2C
0.310
48
V, positive logic 2 x HE 10 connectors 32 isolated inputs, type 2
TSX DEY 32D3KC
0.310
50/60
Hz
a
inputs
24
V
Screw terminal block 16 isolated inputs, type 2
TSX DEY 16A2C
0.310
48
V
Screw terminal block 16 isolated inputs, type 2
TSX DEY 16A3C
0.320
100...120
V
Screw terminal block 16 isolated inputs, type 2
TSX DEY 16A4C
0.320
200...240
V
Screw terminal block 16 isolated inputs, type 2
TSX DEY 16A5C
0.360
Solid state
c
outputs
24
V/0.5 A, pos. logic Screw terminal block 8 protected outputs
TSX DSY 08T2C
0.320
24
V/2 A, pos. logic Screw terminal block 8 protected outputs
TSX DSY 08T22C
0.410
24
V/0.5 A, pos. logic Screw terminal block 16 protected outputs
TSX DSY 16T2C
0.340
48
V/1 A, pos. logic Screw terminal block 8 protected outputs
TSX DSY 08T31C
0.320
48
V/0.25A, pos. logic Screw terminal block 16 protected outputs
TSX DSY 16T3C
0.340
24
V/0.1 A, pos. logic 2 x HE 10 connectors 32 protected outputs
TSX DSY 32T2KC
0.300
4
x HE 10 connectors 64 protected outputs
TSX DSY 64T2KC
0.360
c
or
a
relay
outputs
24
V
c
/3
A,
24
to 240 V
a
/3
A
Screw terminal block 8 non-protected outputs
TSX DSY 08R5C
0.330
Screw terminal block 16 non-protected outputs
TSX DSY 16R5C
0.380
24
to 48 V
c
/5
A,
24
to 240 V
a
/5
A
Screw terminal block 8 protected outputs
TSX DSY 08R5AC
0.420
c
relay outputs
24...120
V 5 A
Screw terminal block 8 protected outputs
TSX DSY 08R4DC
0.370
a
triac outputs
4...120
V 1 A
Screw terminal block 16 non-protected outputs
TSX DSY 16S4C
0.380
c
I/O
I: 24 V pos. logic
O: 24 V/0.5 A
2
x HE 10 connectors 16 isolated fast inputs, type 1
12
protected outputs
TSX DMY 28FKC
0.320
16
isolated fast inputs, type 1
12
reflex or time-delayed
protected outputs
TSX DMY 28RFKC
0.355
For
screw terminal block, connection accessories and separate parts
,
see page 3/11.
Analog I/O modules
Type
Description
Connection by
Reference
Weight
kg
Analog inputs
4
x 16-bit high level voltage/current channels 25-way SUB-D connector
TSX AEY 420C
0.330
4
x 16-bit isolated low level voltage/current
temperature probe/thermocouple channels
Screw terminal block
TSX AEY 414C
0.320
8
x 12-bit high level voltage/current channels 25-way SUB-D connector
TSX AEY 800C
0.310
16
x 12-bit high level voltage/current channels 25-way SUB-D connector
TSX AEY 1600C
0.340
8
x 16-bit isolated high level voltage/current
channels
25-
way SUB-D connector
TSX AEY 810C
0.330
16
x 16-bit thermocouple channels
25-
way SUB-D connector
TSX AEY 1614C
0.350
Analog outputs
4
x 11-bit + sign voltage/current channels
Screw terminal block
TSX ASY 410C
0.350
8
x 13-bit + sign voltage/current channels
25-
way SUB-D connector
TSX ASY 800C
–
For
screw terminal block, connection accessories and separate parts
,
see page 3/17.
TSX PSY double format
TSX DEY/DSY/AEY/ASY
with screw terminal block
TSX DEY/DMY 32/24 channels
with HE 10 connectors
TSX DEY/DSY 64 channels
with HE 10 connectors
TSX AEY/ASY with 25-way
SUB-D connector
Modicon Premium automation
platform
0
Treatment for harsh environments
Conformal Coating modules
References
(
continued)
Presentation:
page 9/2
