393 / 413
9/5
Modicon Premium automation
platform
0
Treatment for harsh environments
Conformal Coating modules
Counter modules
Type of input
Function
No. of
channels
Reference
Weight
kg
24
V
c
2/3-
wire sensors
5
V
c
RS 232 and 10...30 V
c
Totem Pole
incremental encoders SSI serial or parallel
absolute encoders
(1)
40
kHz counting
2
TSX CTY 2AC
0.320
4
TSX CTY 4AC
0.430
40
kHz counting and
measurement
2
TSX CTY 2CC
0.340
Electronic cam
1
TSX CCY 1128C
0.480
For accessories and connecting cables
,
see pages 4/19, 4/23 and 4/25.
(1)
With
TSX CTY 2CC
and
TSX CCY 1128C
modules.
Motion control modules
Type of input
Function
No. of
channels
Reference
Weight
kg
Translator with RS422 I/O, 5 V
c
TTL inputs
and 5 V
c
open collector outputs
Modules for stepper motors
1
TSX CFY 11C
0.440
2
TSX CFY 21C
0.480
5
V
c
RS 232 and 10...30 V
c
Totem Pole
incremental encoders RS 485 or parallel
absolute encoders
Modules for servo motors
500
kHz counting (with incremental
encoder), 200 kHz counting (with
serial absolute encoder)
(1)
2
TSX CAY 21C
0.480
4
(2)
TSX CAY 41C
0.610
2
TSX CAY 22C
0.480
4
(2)
TSX CAY 42C
0.610
3
(2)
TSX CAY 33C
0.610
For
accessories and connecting cables
,
see page 4/33.
(1)
With servo control functions on independent infinite axis, follower axes and flying shear for
TSX CAY
p
2
C
modules.
(2)
Double format module. The other motion control modules are single format.
Weighing module
Description
Function
Reference
Weight
kg
ISP
Plus
weighing module
1
weigher/module, 1…8 load cells
TSX ISP Y101C
0.420
For
remote indicator and accessories
,
see page 4/51.
Communication
Description
Function
Reference
Weight
kg
Ethernet Modbus/TCP
network modules
10
Mbps, Transparent Ready class C10
TSX ETY 110WSC
0.370
10/100
Mbps, Transparent Ready class B30
TSX ETY 4103C
0.370
10/100
Mbps, Transparent Ready class C30
TSX ETY 5103C
0.370
10/100
Mbps, Transparent Ready class D10
TSX WMY 100C
0.370
PCMCIA cards
CANopen
Master V4.02
TSX CPP 110C
0.230
Modbus Plus 1 Mbps network, 64 stations max.
TSX MBP 100C
0.110
Serial links
Modbus, Uni-Telway,
Character mode
RS 232
TSX SCP 111C
0.105
RS 485
TSX SCP 114C
0.105
20
mACL
TSX SCP 112C
0.105
Communication modules
1
Modbus RS 485 integrated channel
TSX SCY 11601C
0.370
1
RS 485 integrated channel, 1 PCMCIA slot
TSX SCY 21601C
0.360
Fieldbus modules
AS-Interface M2E master profile, V2
TSX SAY 1000C
0.340
I
NTER
B
US
0.5
Mbps master/slave, generation 4
TSX IBY 100C
0.280
ConneXium managed
switches
8
extended ports
Ethernet
Modbus/TCP
network
8
x 10/100BASE-TX ports (copper cable)
TCS ESM 083F23F1C
1.000
6
x 10/100BASE-TX ports (copper cable)
2
x 100BASE-FX ports (multimode optical fibre)
TCS ESM 063F2CU1C
1.000
6
x 10/100BASE-TX ports (copper cable)
2
x 100BASE-FX ports (multimode optical fibre)
TCS ESM 063F2CS1C
1.000
Profibus Remote Master
(
PRM) module
Modbus TCP/Profibus DP V1 gateway and
Profibus PA (via gateway)
TCS EGPA23F14FK
–
For
connecting cables and accessories
,
see pages 5/66 and 5/67 (Ethernet), 5/90 and 5/91 (CANopen), 5/116 and 5/117
(
Modbus Plus), 5/126 and 5/127 (Modbus), 5/130 and 5/131 (Uni-Telway), 5/133 (serial link), 5/96...5/97 (AS-Interface), 5/119
(
Profibus DP) and 5/122 and 5/123 (I
NTER
B
US
).
TSX CTY 2AC/2CC
TSX CAY 41C/42C
TSX ISP Y101C
TSX ETY
p
103
C/WMY 100C
TSX MBP/SCP 1
pp
C
References
(
continued)
TCS EGPA23F14FK
