Modicon Premium automation
platform
0
Treatment for harsh environments
Conformal Coating modules
References
Racks
Description
Capacity
Reference
Weight
kg
Non-extendable racks
6
positions
TSX RKY 6C
1.470
8
positions
TSX RKY 8C
1.760
12
positions
TSX RKY 12C
2.310
Extendable racks
Requires 1 x
TSX TLY EX
line
terminator on the 2 end racks
Sold in lots of 2
4
positions
TSX RKY 4EXC
1.160
6
positions
TSX RKY 6EXC
1.500
8
positions
TSX RKY 8EXC
1.780
12
positions
TSX RKY 12EXC
2.340
For
connection accessories
,
see page 2/5.
Premium TSX 57 Unity processors
I/O capacity
Capacity
Integrated
port
Reference
Weight
kg
Memory
Network
TSX 57 1
p
512
discrete I/O,
24
analog I/O and 8 application-specific channels
96
KB integrated
224
KB on PCMCIA
1
–
(1)
TSX P57 104MC
0.380
0
Ethernet
TSX P57 1634MC
–
1
Fipio
(1)
TSX P57 154MC
0.420
TSX 57 2
p
1024
discrete I/O,
80
analog I/O and 24 application-specific channels
160
KB integrated
768
KB on PCMCIA
1
–
TSX P57 204MC
0.520
–
Ethernet
TSX P57 2634MC
–
192
KB integrated
768
KB on PCMCIA
2
Dedicated
Hot Standby
TSX H57 24MC
0.560
1
Fipio
TSX P57 254MC
–
TSX 57 3
p
1024
discrete I/O,
128
analog I/O and 32 application-specific channels
192
KB integrated
1792
KB on PCMCIA
3
–
TSX P57 304MC
0.520
2
Ethernet
TSX P57 3634MC
–
208
KB integrated
1792
KB on PCMCIA
3
Fipio
TSX P57 354MC
0.560
TSX 57 4
p
2040
discrete I/O,
256
analog I/O and 64 application-specific channels
440
KB integrated
2048
KB on PCMCIA
3
Ethernet
TSX P57 4634MC
0.610
4
Dedicated
Hot Standby
TSX H57 44MC
0.610
4
Fipio
TSX P57 454MC
0.560
TSX 57 5
p
2040
discrete I/O,
512
analog I/O and 64 application-specific channels
1
MB integrated
7168
KB on PCMCIA
3
Ethernet
TSX P57 5634MC
0.610
4
Fipio
TSX P57 554MC
0.560
TSX 57 6
p
2040
discrete I/O,
512
analog I/O and 64 application-specific channels
2
MB integrated
7168
KB on PCMCIA
3
Ethernet
TSX P57 6634MC
0.610
For
connecting cables
,
see page 1/11.
Premium TSX 57 PL7 processors
TSX 57 1
p
512
discrete I/O,
24
analog I/O and 8 application-specific channels
32
Kwords integrated,
644
Kwords on
PCMCIA
1
–
(1)
TSX P57 103MC
0.380
0
Fipio
(1)
TSX P57 153MC
0.420
TSX 57 2
p
1024
discrete I/O,
80
analog I/O and 24 application-specific channels
48
Kwords integrated,
160
Kwords on
PCMCIA
1
–
TSX P57 203MC
0.520
–
Ethernet
TSX P57 2623MC
–
64
Kwords integrated,
160
Kwords on
PCMCIA
1
Fipio
TSX P57 253MC
0.560
–
Ethernet and
Fipio
TSX P57 2823MC
–
TSX 57 3
p
1024
discrete I/O,
128
analog I/O and 32 application-specific channels
64/80
Kwords
integrated
(2)
384
Kwords on PCMCIA
3
–
TSX P57 303AMC
0.520
2
Ethernet
TSX P57
3623
AMC
–
80/96
Kwords
integrated
(2)
384
Kwords on PCMCIA
3
–
(1)
TSX P57
353
LAMC
–
Fipio
TSX P57 353AMC
0.560
TSX 57 4
p
2040
discrete I/O,
256
analog I/O and 64 application-specific channels
96/176
Kwords
integrated
(2)
992
Kwords on PCMCIA
4
Fipio
TSX P57 453AMC
0.560
4
Ethernet and
Fipio
TSX P57
4823
AMC
–
PCMCIA SRAM memory extension cards
Description
Memory size
Reference
Weight
kg
Application
Additional data
Configurable application/additional
data memory extensions
(
slot 0 in processors)
192
KB…1024 KB 832 KB…0 KB
TSX MRP C001MC
0.076
192
KB…3072 KB 2880 KB…0 KB
TSX MRP C003MC
0.076
192
KB…7168 KB 6976 KB…0 KB
TSX MRP C007MC
0.076
For
replacement parts
,
see page 1/21.
(1)
Single format module. The other processors are double format.
(2)
The second value corresponds to the integrated memory capacity when the processor is equipped with a PCMCIAmemory card.
Presentation:
page 9/2
TSX RKY 6C
TSX P57 1634MC
TSX P57
25
p
MC/35
p
MC/453AMC
TSX P57 4634MC
5634
MC/6634MC
TSX MRP C00
p
MC
