Presentation
Power supplies for AS-Interface cabling system
Consistent with the standard Phaseo line, the range of
ASI ABL
power supplies is
designed to deliver a
c
voltage, as required by AS-Interface cabling systems. Three
versions are available to meet all needs encountered in industrial applications, in
enclosures, cells or floor-standing enclosures. These single-phase, electronic,
switch mode power supplies guarantee the quality of the output current, in
accordance with the electrical characteristics and conforming to standard EN 50295.
ASI ABLB300
p
Operating on a 100 to 240 V
a
supply, this power supply delivers a voltage of
30
V
c
.
Available in 2.4 and 4.8 A ratings, the outgoing terminal block allows the
cable to be connected separately to the
AS-Interface interface modules and to the AS-Interface master. Input and output
LEDs allow fast and continuous diagnostics.
ASI ABLD300
p
Operating on a 100 to 240 V
a
supply, this power supply delivers a voltage of
30
V
c
.
Available in 2.4 and 4.8 A ratings, it allows diagnosis and management of
earth faults on AS-Interface interface modules. In the event of an earth fault, the
Phaseo power supply stops dialogue on the AS-Interface cabling system and puts
the installation in a fallback condition. Restarting is only possible after deliberate
acknowledgement of the fault. Two inputs/outputs enable dialogue with a processing
unit. The outgoing terminal block is used to connect the AS-Interface cable
separately to the interface modules and master modules. Input, output and earth fault
LED’s allow fast and continuous diagnostics.
ASI ABLM3024
Operating on a 100 to 240 V
a
supply, this product provides two separate power
supplies, which are totally independent in the way they operate.
Two output voltages - 30 V/2.4 A (AS-Interface line supply) and 24 V/3 A - are
available, so making it possible to supply the control equipment without an additional
power supply. Input and output LEDs allow fast and continuous diagnostics.
ASI ABLB3002
ASI ABLD3004
ASI ABLM3024
Power supplies and transformers
Phaseo
Regulated switch mode power supplies
ASIABL
Power supplies for AS-Interface cabling system
