References
Power supplies and transformers
Phaseo
Regulated switch mode power supplies
ABL4
85
to 960 W - Compact - Rail mounting
Phaseo regulated switch mode power supplies ABL4, 85 to 960 W
Input voltage Secondary
Reset
Reference
Weight
kg
Output
voltage
Nominal
power
Nominal
current
Single-phase
(
N-L1)
connection (1)
a
100…230
V
- 10%,
+ 15%
c
23…27.4
V 85 W
3.5
A
Automatic
ABL 4RSM24035
0.500
120
W 5 A
Automatic
ABL 4RSM24050
0.500
a
120
V
- 25%,
+ 10%
and
a
230
V
- 20%,
+ 15%
c
23…27.4
V 240 W 10 A
Automatic
ABL 4RSM24100
0.800
c
24…27.8
V 480 W 20 A
Automatic
ABL 4RSM24200
(2)
1.300
3-
phase
(
L1-L2-L3) connection
a
400…500
V
- 15%,
+ 10%
c
24…27.8
V 480 W 20 A
Automatic
ABL 4WSR24200
1.300
720
W 30 A
Automatic
ABL 4WSR24300
1.300
960
W 40 A
Automatic
ABL 4WSR24400
1.300
Function modules for continuity of service
(3)
Function
Use
Description
Reference
Weight
kg
Continuity after
a power outage
(5)
Holding time 100 ms
at 40 A and 2 s at 1 A
Buffer module
ABL 8BUF24400
1.200
Holding time 9 min at 40 A...2 hrs at 1 A
(
depending on use with a battery check
module-battery unit and load)
(4)
Battery check module,
output current 20 A
ABL 8BBU24200
0.500
Battery check module,
output current 40 A
ABL 8BBU24400
0.700
Battery module, 3.2 Ah
(6)
ABL 8BPK24A03
3.500
Battery module, 7 Ah
(6)
ABL 8BPK24A07
6.500
Battery module, 12 Ah
(6)
ABL 8BPK24A12
12.000
Continuity after
a malfunction
Paralleling and redundancy of the power supply
to ensure uninterrupted operation of the
application excluding AC line failures and
application overcurrents
Redundancy module
ABL 8RED24400
0.700
Discriminating
downstream
protection
Electronic protection (1...10 A overcurrent or
short-circuit) of 4 output terminals from an ABL4
power supply
Protection module with 2-pole
breaking
(7) (8)
ABL 8PRP24100
0.270
Converters
c
/
c
(3)
Primary
(9)
Secondary
Reference
Weight
kg
Input voltage Power supply module output current
Output
voltage
Nominal
current
c
24
V
- 9%,
+ 24%
2.2
A
c
5...6.5
V 6 A
ABL 8DCC05060
0.300
1.7
A
c
7...15
V 2 A
ABL 8DCC12020
0.300
Separate and replacement parts
Description Use
Composition
Unit reference Weight
kg
Fuse
assemblies
Discriminating Protection module
ABL 8PRP24100
4
x 5 A, 4 x 7.5 A and 4 x 10 A
ABL 8FUS01
–
Battery ABL 8BKP24A
pp
4
x 20 A and 6 x 30 A
ABL 8FUS02
–
Clip-on marker
labels
All products except ABL 8PRP24100
Sold in lots of 100
LAD 90
0.030
Discriminating Protection module
ABL 8PRP24100
Sold in lots of 22
ASI20 MACC5
–
Rail mounting
kit
Battery module ABL 8BPK2403
–
ABL 1A02
–
EEPROM
memory
Backup and duplication of ABL8 BBU24
p
00
battery check module parameters
–
SR2 MEM02
0.010
(1) 2-
phase connection possible on certain American line supplies.
(2)
Power supply reference
ABL 4RSM24200
has an integrated redundancy diode.
(3)
For use with power supply ABL4.
(4)
Compatibility table for battery check module-battery unit with holding time depending on the load.
More technical information on
www.schneider-electric.com(5)
Appendices, see page 8/34.
(6)
Supplied with 20 or 30 A fuse depending on the model.
(7)
Supplied with four 15 A fuses.
(8)
Local reset via pushbutton or automatic reset on elimination of the fault.
(9)
Voltage from power supply ABL4.
ABL 4RSM24050
ABL 4RSM24100
ABL 4WSR24200
ABL 8BUF24400
ABL 8BBU24200
ABL 8RED24400
