8/32
Characteristics
(
continued),
description
Power supplies and transformers
Phaseo
Regulated switch mode power supplies
ABL4
85
to 960 W - Compact - Rail mounting
Characteristics
(
continued)
Selection of protection on the power supply primaries
Power supply
Type of protection
Miniature circuit-
breakers C60N
(
Icn > 1.5 kA)
Fuses
Class CC fuses with
rejection system
Zone in which equipment used
Rest of the world
USA & Canada
ABL 4RSM24035
4
A curve C
4
A time-lag
6
A
ABL 4RSM24050
4
A curve C
4
A time-lag
6
A
ABL 4RSM24100
6
A curve C
6.3
A time-lag
6
A
ABL 4RSM24200
16
A curve C
10
A curve D
15
A time-lag
10
A
ABL 4WSR24200
3
x 10 A curve C
3
x 3.15 A time-lag
3
x 10 A
ABL 4WSR24300
3
x 10 A curve C
3
x 5 A time-lag
3
x 10 A
ABL 4WSR24400
3
x 10 A curve C
3
x 6.3 A time-lag
3
x 10 A
Description
The regulated switch mode power supplies ABL 4RSM24035 and ABL 4RSM24050
comprise:
1
Spring clip for Omega (
5
35
mm) rail.
2
Output voltage status LED (green).
3
Output circuit overcurrent LED (red).
4
Output voltage adjustment potentiometer.
5
Removable screw terminal block for connection of the DC output voltage and
diagnostics contact.
6
Removable screw terminal block for connection of the AC input voltage on
single-phase
(1)
.
The regulated switch mode power supplies ABL 4RSM24100 comprise:
1
Spring clip for Omega (
5
35
mm) rail.
2
Removable screw terminal block for connection of the AC input voltage (on
single-phase)
(1)
)
and for connection of 120/230 V selection link.
3
Output voltage status LED (green).
4
Output circuit overcurrent LED (red).
5
Output voltage adjustment potentiometer.
6
Removable screw terminal block for connection of the DC output voltage and
diagnostics contact.
The regulated switch mode power supplies ABL 4RSM24200, ABL 4WSR24200,
ABL 4WSR24300 and ABL 4WSR24400 comprise:
1
Spring clip for Omega (
5
35
mm) rail.
2
Enclosed screw terminals for connection of the DC output voltage and diagnostics
contact.
3
Output voltage adjustment potentiometer.
4
Output voltage status LED (green).
5
Output circuit overcurrent and alarm LED (red).
6
Enclosed screw terminals for connection of the AC input voltage:
-
single-phase connection for ABL 4RSM24200
(1)
,
- 3-
phase connection for ABL 4W
pppp
.
(1)
Connection between 2 phases only on certain American line supplies.
2
4
5
6
3
1
4
1
2
5
6
3
2
1
3
4
5
6
