Phaseo power supplies and
transformers
Regulated switch mode power supplies
ABL 8MEM, ABL 7RM
7
to 60 W - Rail mounting
Combinations,
references
Selection of protection on the power supply primaries
Type of line supply
100
to 240 V
a
single-phase
Type of protection
Thermal-magnetic circuit breaker
gG fuse
GB2 (IEC)
(1)
C60N (IEC)
C60N (UL/CSA)
ABL 8MEM05040
GB2
pp
07
(2)
24581
24517
2
A
ABL 8MEM12020
ABL 8MEM24003
ABL 8MEM24006
ABL 8MEM24012
ABL 7RM24025
GB2
pp
08
(2)
24582
24518
3
A
(1)
UL pending
(2)
Complete the reference by replacing
pp
with:
CB
:
for single-pole circuit-breaker with magnetic trip threshold 12 to 16 In
CD
:
for single-pole + neutral circuit-breaker with magnetic trip threshold 12 to 16 In
DB
:
for 2-pole circuit-breaker with magnetic trip threshold 12 to 16 In
CS
:
for single-pole circuit-breaker with magnetic trip threshold 5 to 7 In
References
Input voltage Secondary
Reset
Conformity
to standard
IEC/EN
61000-3-2
(1)
Reference
Weight
kg
Output
voltage
Nominal
power
Nominal
current
Single-phase
(
N-L1)
or 2-phase
(
L1-L2)
connection
100…240
V
-15%,
+ 10%
50/60
Hz
5
V
c
20
W 4 A
Automatic Not applicable
ABL 8MEM05040
0.195
12
V
c
25
W 2 A
Automatic Not applicable
ABL 8MEM12020
0.195
24
V
c
7
W 0.3 A Automatic Not applicable
ABL 8MEM24003
0.100
15
W 0.6 A Automatic Not applicable
ABL 8MEM24006
0.100
30
W 1.2 A Automatic Not applicable
ABL 8MEM24012
0.195
60
W 2.5 A Automatic Not applicable
ABL 7RM24025
0.255
Description Use
Order in
multiples of
Unit reference Weight
kg
Clip-on marker
tags
Replacement parts for ABL 8MEM power supplies
100
LAD 90
0.030
(1)
Due to their power < 75 W,
ABL 8MEM/7RM
power supplies are not subject to the requirements of standard
IEC/EN 61000-3-2.
ABL 8MEM05040/12020/2401
2
ABL 8MEM24003/24006
ABL 7RM24025
