Selection of protection on the power supply primaries
Type of line supply
100
V
a
240
V
a
Type of protection
Thermal-magnetic circuit
breaker
gG fuse
Thermal-magnetic circuit
breaker
gG fuse
GB2 (IEC)
(1)
C60N (IEC)
C60N (UL)
GB2 (IEC)
(1)
C60N (IEC)
C60N (UL)
ABL 7RP1205
GB2
pp
06
(2)
24580
24516
2
A
GB2
pp
06
(2)
24580
24516
1
A
ABL 8REM24030
GB2
pp
07
(2)
24581
24517
2
A
GB2
pp
06
(2)
24580
24516
1
A
ABL 8REM24050
GB2
pp
07
(2)
24581
24517
2
A
GB2
pp
06
(2)
24580
24516
1
A
ABL 7RP4803
GB2
pp
07
(2)
24581
24517
2
A
GB2
pp
06
(2)
24580
24516
1
A
(1)
UL pending
(2)
Complete the reference by replacing
pp
with:
CB:
for single-pole circuit-breaker with magnetic trip threshold 12 to 16 In
CD:
for single-pole + neutral circuit-breaker with magnetic trip threshold 12 to 16 In
DB:
for 2-pole circuit-breaker with magnetic trip threshold 12 to 16 In
CS:
for single-pole circuit-breaker with magnetic trip threshold 5 to 7 In
ABL 8REM/7RP range of Phaseo regulated switch mode power supplies
Input voltage Secondary
Reset
Conformity
to standard
IEC/EN 61000-3-2
Reference
Weight
kg
Output
voltage
Nominal
power
Nominal
current
Single-phase (N-L1) or phase-to-phase (L1-L2) connection
100...240
V
a
- 15%,
+ 10%
50/60
Hz
12
V
c
60
W 5 A
Automatic
or manual
Yes
ABL 7RP1205
1.000
24
V
c
72
W 3 A
Automatic No
ABL 8REM24030
0.520
120
W 5 A
Automatic No
ABL 8REM24050
1.000
48
V
c
144
W 2.5 A Automatic
or manual
Yes
ABL 7RP4803
1.000
Phaseo power supplies and
transformers
Regulated switch mode power supplies
ABL 8REM, ABL 7RP
60
to 144 W - Rail mounting
Combinations,
references
ABL 7RP1205/4803
ABL 8REM24030 ABL 8REM24050
