Display of text messages, graphic objects and synoptic views
Control and configuration of data
Portable Advanced Panels
Open touch screen Advanced Panels
Colour TFT LCD
(640
x 480 pixels)
Colour TFT LCD
(800
x 600 pixels)
Colour TFT LCD
(800
x 600 pixels)
Colour TFT LCD
(1024
x 768 pixels)
5.7" (
colour)
8.4" (
colour)
12" (
colour)
15" (
colour)
Via touch screen
Via touch screen
11
–
–
–
–
–
–
–
32
MB Flash EPROM
1
GB CF system card included with
terminal, expandable to 4 GB
2
GB CF system card included with terminal,
expandable to 4 GB
By means of 128, 256, 512 MB, 1, 2 or 4 GB CF card
Limited by capacity of internal Flash EPROM memory or CF card memory
Unlimited (8000 variables max.)
Alphanumeric, bitmap, bargraph, gauge, tank, tank level indicator, curves, polygon, button, LED
32
groups of 64 recipes comprising 1024 ingredients max.
Yes, with log
Yes
Built-in
–
1
audio output
Uni-TE (2), Modbus, Modbus TCP/IP
and for PLC brands: Mitsubishi,
Omron, Rockwell
Automation and Siemens
Uni-TE
(2)
,
Modbus, Modbus TCP/IP
(1)
and for PLC brands: Mitsubishi, Omron, Allen-Bradley and Siemens
RS 232C/RS 422-485 (COM1)
RS 232C (COM1)
RS 232C (COM2)
RS 232C (COM1)
RS 232C (COM1)
RS 232C (COM2)
1
4
4
+ 1 on front
–
Modbus Plus with USB gateway
1
Ethernet port (10BASE-T/100BASE-
TX)
1
TCP/IP Ethernet port (10BASE-T/100BASE-TX) and 1 Ethernet port (10BASE-T/100BASE-TX/1 GB)
–
RS 232C (COM1 or COM2) serial link, USB port for parallel printer
Vijeo Designer (on Windows XP, Windows Vista and Windows 7)
Magelis
(266
MHz RISC CPU)
Windows XP Embedded
XBT GH 2460
XBT GTW 450
XBT GTW 652
HMI GTW 7353
Please consult the “Human/Machine Interfaces” catalogue
(1)
Depending on model.
(2)
Uni-TE version V2 for Twido controller and TSX Micro/Premium platform.
