Selection guide
Operator dialogue terminals
Magelis GT, GK, GH and GTWAdvanced
Panels
Applications
Display of text messages, graphic objects and synoptic views
Control and configuration of data
Type of terminal
Touch screen Advanced Panels
Display
Type
Backlit monochrome (amber or
red mode) STN LCD
(320
x 240 pixels) or TFT LCD
Backlit monochrome or colour
STN LCD or backlit colour
TFT LCD (320 x 240 pixels) or
(640
x 480 pixels)
(3)
Backlit colour STN LCD or
colour TFT LCD
(640
x 480 pixels)
Capacity
3.8" (
monochrome or colour)
5.7" (
monochrome or colour)
7.5" (
colour)
Data entry
Via touch screen
Static function keys
–
Dynamic function keys
–
Service keys
–
Alphanumeric keys
–
Memory capacity
Applications
32
MB Flash EPROM
16
MB Flash EPROM
(3)
32
MB Flash EPROM
Expansion
–
By means of 128, 256, 512 MB, 1, 2 or 4 GB CF card (except
XBT GT2110)
Functions
Maximum number of pages
Limited by internal Flash
EPROM memory capacity
Limited by capacity of internal Flash EPROM memory or CF
card memory
Variables per page
Unlimited (8000 variables max.)
Representation of variables
Alphanumeric, bitmap, bargraph, gauge, tank, tank level indicator, curves, polygon, button,
LED
Recipes
32
groups of 64 recipes comprising 1024 ingredients max.
Curves
Yes, with log
Alarm logs
Yes
Real-time clock
Built-in
Discrete I/O
–
1
input (reset) and 3 outputs
(
alarm, buzzer, run)
Multimedia I/O
–
(3)
1
audio input (microphone),
1
composite video input
(
digital or analogue video
camera), 1 audio output
(
loudspeaker)
(1)
Communication
Downloadable protocols
Uni-TE
(2)
,
Modbus, Modbus TCP/IP
(1)
and for PLC brands: Mitsubishi, Omron, Allen-Bradley
and Siemens
Asynchronous serial link
RS 232C/485 (COM1)
RS 232C/RS 422/485 (COM1) and RS 485 (COM2)
USB ports
1
1
(3)
1
Bus and networks
–
Modbus Plus and Fipway with USB gateway, PROFIBUS DP
and Device Net with optional card
Ethernet TCP/IP (10BASE-T/100BASE-TX)
(1)
Printer link
USB port for parallel printer
RS 232C (COM1) serial link, USB port for parallel printer
Development software
Vijeo Designer (on Windows XP, Windows Vista and Windows 7)
Operating system
Magelis
(200
MHz RISC CPU)
Magelis
(133
MHz RISC CPU)
(3)
Magelis
(266
MHz RIS CPU)
Type of terminal
XBT GT11/13
XBT GT21/22/23/24/29 XBT GT42/43
Page
Please consult the “Human/Machine Interfaces” catalogue
(1)
Depending on model.
(2)
Uni-TE version V2 for Twido controller and TSX Micro/Premium platform.
(3)
For XBTGT 2430, 32 MB Flash EPROM, 1 sound output, 2 USB ports, 266 MHz RISC CPU.
(4)
For XBT GT 5430.
