Schneider Electric Modicon Premium Automation Platform, May 2012

7/11

Traditional architecture, HMI executed on PC platform or dedicated terminal

Configuration software for operator dialogue applications

Magelis

STO/STU Small Panels

Magelis

XBT GT

GK/GH/GTW and Magelis

GTOAdvanced Panels

(1)

Magelis

industrial PCs

Proprietary for Magelis STO/STU, Magelis XBT GT/GK/GH and Magelis GTO

Windows XP embedded for Magelis GTW

Yes, up to 8000 internal and external variables

Yes

Yes, using expression editor or Java programming

Up to 300 variables between 8 terminals, without router PLC

Proprietary protocol above TCP/IP

Yes, with the Intelligent Data Service extension

Up to 15 languages supported by 34 western alphabets, 4 Asian alphabets and 2 middle eastern alphabets embedded in the application

Yes

Yes, with log

Java

Via I/O drivers: Schneider Electric or third party protocols (Mitsubishi, Omron, Rockwell Automation, Siemens)

(3)

Yes

Yes, up to 32 groups, 1024 ingredients for 256 recipes per group, proprietary or CSV format, complete multilingual support for labels and ingredients

On the fly alarms, log data. Up to 9999 active alarms, record or logs

Main barcode types supported: UPC-A, UPC-E, JAN/EAN8, JAN/EAN13, ITF, CODE39, CODE93, CODE128, CODABAR (NW-7)

Yes, for Magelis XBT GT (XBT GT 1105 and higher), Magelis GTO and Magelis industrial PCs. JPEG format

Linked to user profiles

Screens, online help and documentation in electronic format available in 7 languages: English, French, German, Italian, Brazilian Portuguese, Simplified Chinese

and Spanish

Windows XP Professional, Windows 7 Business (32-bit and 64-bit)

Vijeo Designer

Please consult the “Human/Machine Interfaces” catalogue
