Selection guide
HMI software
Applications
Traditional architecture, HMI executed on PC platform or dedicated terminal
Configuration software for operator dialogue applications
Compatible products
Type
Magelis
TM
XBT N/R/RT Small Panels
(1)
Maximum number of targets
1
Operating system on terminals
Proprietary Magelis
Functions
Reading/writing of PLC variables
Yes
Display of variables
Yes
Data processing
–
Sharing of variables between HMI
applications
–
Saving of variables to external
database
–
Internationalization
–
Development of graphic
applications
Native library of graphic objects
Yes
Curves and alarms
Yes
(2)
Scripts
–
Communication between HMI application and PLCs
Via I/O drivers: Schneider Electric or third party protocols (Mitsubishi, Omron, Rockwell
Automation, Siemens)
(3)
Uploading of applications
Yes
Simulation of HMI applications
Yes
Recipe management
–
Report and barcode printing
–
Screen capture
–
Access security
Linked to user profiles
Interface languages
Screens, online help and documentation in electronic format available in 6 languages:
English, French, German, Italian, Simplified Chinese and Spanish
OS compatibility
Windows XP Professional, Windows Vista Business (32-bit), Windows 2000 Professional
Software type
Vijeo Designer
TM
Lite
Page
Please consult the “Human/Machine Interfaces” catalogue
(1)
All Magelis XBT and Magelis GTO terminals behave transparently on restoration of power.
(2)
Depending on compatible product.
(3)
See protocols supported on page, please consult the “Human/Machine Interfaces” catalogue.
