Display of text messages, graphic objects and synoptic views
Control and configuration of data
Touch screen Advanced Panels
Backlit colour STN LCD or colour TFT LCD
(640
x 480 pixels or 800 x 600 pixels)
(4)
Backlit colour TFT LCD (800 x 600 pixels)
Backlit colour TFT LCD (1024 x 768 pixels)
10.4" (
colour)
12.1" (
colour)
15" (
colour)
Via touch screen
–
–
–
–
32
MB Flash EPROM
By means of 128, 256, 512 MB, 1, 2 or 4 GB CF card
Limited by capacity of internal Flash EPROM memory or CF card memory
Unlimited (8000 variables max.)
Alphanumeric, bitmap, bargraph, gauge, tank, tank level indicator, curves, polygon, button, LED
32
groups of 64 recipes comprising 1024 ingredients max.
Yes, with log
Yes
Built-in
1
input (reset) and 3 outputs (alarm, buzzer, run)
1
audio input (microphone), 1 composite video input (digital or analogue video camera), 1 audio output (loudspeaker)
(1)
Uni-TE
(2)
,
Modbus, Modbus TCP/IP
(1)
and for PLC brands: Mitsubishi, Omron, Allen-Bradley and Siemens
RS 232C/RS 422/485 (COM1) and RS 485 (COM2)
2
Modbus Plus with USB gateway
Ethernet TCP/IP (10BASE-T/100BASE-TX)
RS 232C (COM1) serial link, USB port for parallel printer
Vijeo Designer (on Windows XP, Windows Vista and Windows 7)
Magelis
(266
MHz RIS CPU)
XBT GT52/53/54
XBT GT63
XBT GT73
Please consult the “Human/Machine Interfaces” catalogue
