Display of text messages, graphic objects and synoptic views
Control and configuration of data
OptimumAdvanced Panels, touch screen
OptimumAdvanced Panels, touch screen, “Stainless Steel” version
IP 65 (IP 67 with addition of a cover)
IP 66K (Front panel with stainless steel frame) for food & beverage
environment
Colour TFT LCD,
backlit
640
x 480 pixels (VGA)
Colour TFT LCD,
backlit
640
x 480 pixels (VGA)
Colour TFT LCD,
backlit
800
x 600 pixels (SVGA)
Colour TFT LCD,
backlit
320
x 240 pixels (QVGA)
Colour TFT LCD,
backlit
640
x 480 pixels (VGA)
Colour TFT LCD,
backlit
800
x 600 pixels (SVGA)
7.5”
10.4”
12.1”
5.7”
10.4”
12.1”
Via touch screen
–
–
–
–
96
MB Flash EPROM
By 4 GB SD card
Limited by capacity of internal Flash EPROM memory or of SD card
Unlimited (8000 variables max.)
Alphanumeric, bitmap, bargraph, gauge, tank, tank level indicator, curves, polygon, button, LED
32
groups of 64 recipes comprising 1024 ingredients max.
Yes, with log
Yes
Built-in
–
–
Uni-TE
(2)
,
Modbus, Modbus TCP/IP
(1)
and for PLC brands: Mitsubishi, Omron, Allen-Bradley and Siemens
RS 232C (COM1) and RS 485 (COM2)
1
type A host connector + 1 mini-B connector
Ethernet TCP/IP (10BASE-T/100BASE-TX), Modbus Plus and Fipway via USB gateway
RS 232C (COM1) serial link and USB port for parallel printer
Vijeo Designer (on Windows XP and Windows 7)
Magelis (333 MHz RISC CPU)
HMI GTO4310 HMI GTO5310 HMI GTO6310 HMI GTO2315 HMI GTO5315 HMI GTO6315
Please consult the “OptimumAdvanced Panels, Magelis
TM
GTO” catalogue
