352 / 413
8/2
Applications
Discrete inputs or outputs
Optimum “Economy” Optimum “Miniature” Universal
Compatibility
TSX Micro,
Modicon Premium,
Modicon M340
TSX Micro, Modicon Premium, Modicon Quantum, Modicon M340
Sub-base type
Passive connection sub-bases
Equipped with relays
–
Control voltage
24
V
c
Output voltage
24
V
c
Output current per channel
0.5
A
Modularity
16
8 -12 -16
No. of terminals per channel
1
1
to 3
1
2
Type of connection terminals
Signal
Signal, common
(
configurable as
24
V
c
or 0 V)
Signal
Signal, common (configurable as 24 V
c
or 0 V)
Connectors
20-
way HE10 connector
Terminal
block
Removable
No
No
Terminal type
Screw
Additional or optional*
function
Low-cost version fitted
with cable
Miniature sub-bases Compact size
*
Input type 2
*
(1)
Isolator
*
Type of device
ABE 7H
pp
E
p
00
ABE 7H16C
pp
ABE 7H
pp
R1
p
ABE 7H
pp
R50
ABE 7H
pp
R2
p
ABE 7H
pp
S21
Page
8/12
8/13
(1)
For Modicon TSX Micro and Modicon Premium PLCs.
Connection interfaces
Modicon Telefast ABE 7 pre-wired system
Discrete input and/or output sub-bases
Selection guide
