356 / 413
8/6
Applications
Analog signals and special functions
Compatibility
TSX Micro:
v
TSX 37 22
v
TSX CTZ
p
A
Modicon Premium:
v
TSX CTY
p
A
v
TSX CAY
p
1
Modicon Premium:
v
TSX ASY810
v
TSX AEY1600
TSX A
p
Y800
Modicon M340:
v
BMX AMI 0800
v
BMX AMI 0810
v
BMX AMO 0802
Modicon Quantum:
v
140
AVI 030 00
v
140
ACI 030 00
v
140
ACI 040 00
v
140
ACO 130 00
Modicon Premium:
v
TSX ASY410
v
TSX AEY420
Modicon M340:
v
BMX AMO0410
Modicon Quantum
v
140
AVO 020 00
v
140
ACO 020 00
Modicon M340:
v
BMX ART 0414
v
BMX ART 0814
Modicon Premium:
v
TSX AEY1614
Type of signal
Counter inputs and
analog I/O
Counter inputs
Axis control
Position control
Analog inputs
Current/Voltage
Pt 100
Analog outputs
Current
Voltage
Analog inputs
Functions
Passive connection, point-to-point with shield continuity
Connection of cold junction
compensation or provision,
distribution of isolated
power supplies
Modularity
1
counter channel or
8
analog inputs + 2 analog outputs
8
channels
4
channels
4
channels
Control voltage
24
V
c
–
Output voltage
24
V
c
–
Output current per channel
25
mA
–
No. of terminals per channel
2
2
or 4
2
or 4
2
or 4
Connector type
15-
way SUB-D + 9-way SUB-D
25-
way SUB-D
25-
way SUB-D
Terminal
block
Removable
No
No
No
Terminal type
Screw
Screw
Screw
Type of device
ABE 7CPA01
ABE 7CPA02
ABE 7CPA21
ABE 7CPA412
ABE 7CPA410
Page
8/18
Connection interfaces
Modicon Telefast ABE 7 pre-wired system
Analog and application-specific sub-bases
Selection guide (continued)
