Passive connection sub-bases for discrete signals
Optimum "Economy" sub-bases
Function
No. of
channels
No. of terminals For PLCs
Length of
PLC
connection
cable
Type of
connection
Reference
Weight
kg
per
channel
on row
number
Input or output
16
1
2
Modicon TSX Micro
Modicon Premium
1
m
Screw
ABE 7H20E100
0.330
2
m
Screw
ABE 7H20E200
0.410
3
m
Screw
ABE 7H20E300
0.480
Modicon M340 –
(1)
Screw
ABE 7H34E000
0.150
1
m
Screw
ABE 7H34E100
0.330
2
m
Screw
ABE 7H34E200
0.410
3
m
Screw
ABE 7H34E300
0.480
Siemens S7
1.5
m Screw
ABE 7H32E150
0.360
3
m
Screw
ABE 7H32E300
0.460
Optimum "Miniature" sub-bases
Function
No. of
channels
No. of terminals LED per channel Polarity
distribution
Type of
connection
Reference
Weight
kg
per
channel
on row
number
Input or output
16
1
1
No
No
Screw
ABE 7H16C10
0.160
Yes
No
Screw
ABE 7H16C11
0.160
2
2
Yes
0
or 24 V Screw
ABE 7H16C21
0.205
3
3
Yes
0
or 24 V Screw
ABE 7H16C31
0.260
Input and output
(2)
16
1
1
Yes
No
Screw
ABE 7H16CM11
0.160
2
2
Yes
0
or 24 V Screw
ABE 7H16CM21
0.200
(1)
Sub-base supplied without cordset.
(2) 8
I + 8 Q: these products have 2 common connections which enable inputs and outputs to be connected to the same
sub-base at the same time.
Connection interfaces
Modicon Telefast ABE 7 pre-wired system
Passive connection sub-bases
References
ABE 7H20E
ppp
ABE 7H16CM21
ABE 7H16C21
