Adaptor sub-bases with fixed solid state relays, removable terminal blocks
Universal input sub-bases with solid state relays
Number of
channels
No. of
terminals
per channel
Isolation of PLC/
Operative part
Voltage
Type of
connection
Reference
Weight
kg
16
2
Yes
c
24
V
Screw
ABE 7S16E2B1
0.370
Spring
ABE 7S16E2B1E
0.370
c
48
V
Screw
ABE 7S16E2E1
0.370
a
48
V
Screw
ABE 7S16E2E0
0.386
a
110
V
Screw
ABE 7S16E2F0
0.397
a
230
V
Screw
ABE 7S16E2M0
0.407
Spring
ABE 7S16E2M0E
0.407
Universal output sub-bases with solid state relays
Number of
channels
Isolation of
PLC/
Operative
part
Output
voltage
Output
current
Fault detection
signal
(1)
Type of
connection
Reference
Weight
kg
16
No
24
V
c
0.5
A
Yes
(2)
Screw
ABE 7S16S2B0
0.405
Spring
ABE 7S16S2B0E
0.405
No
Screw
ABE 7S16S1B2
0.400
Spring
ABE 7S16S1B2E
0.400
Optimum and Universal output sub-bases with electromechanical relays
Number of
channels
Number of contacts
Output
current
Polarity
distribution/
operative part
Type of
connection
Reference
Weight
kg
8
1
N/O
2
A
Contact common
per group of 4
channels
Screw
ABE 7R08S111
0.252
Latching
2
A
Volt-free
Screw
ABE 7R08S216
0.448
1
N/O
5
A
Volt-free
Screw
ABE 7R08S210
0.448
16
1
N/O
2
A
Contact common
per group of 8
channels
Screw
ABE 7R16S111
0.405
Spring
ABE 7R16S111E
0.405
1
N/O
5
A
Volt-free
Screw
ABE 7R16S210
0.405
Spring
ABE 7R16S210E
0.405
Common per
group of
8
channels on
both poles
Screw
ABE 7R16S212
0.400
(1)
A fault on a sub-base output Qn will set PLC output Qn to safety mode, which will be detected by the PLC.
(2)
Can only be used with modules with protected outputs.
Connection interfaces
Modicon Telefast ABE 7 pre-wired system
Adaptor sub-bases with fixed relays and removable
terminal blocks
References
(
continued)
ABE 7R08S216
ABE 7H16E2
