Connection interfaces
Modicon Telefast ABE 7 pre-wired system
Cabled connectors for Modicon Quantum I/O modules
References
(
continued)
Cabled connectors for Modicon Quantum I/O modules
Type of
signal
I/O
modules
Type of
connector
Gauge Cross-
section
Length No. of
channels
Reference Weight
AWG mm²
m
kg
Inputs and
relay outputs
Please consult
our website
www.schneider-electric.com2
x 20-way
HE 10
22
0.324 1.5 2
x 16
ABF M32H150
0.650
3
2
x 16
ABF M32H300
1.150
0.5
A outputs
Please consult
our website
www.schneider-electric.com2
x 20-way
HE 10
+ external
power supply
22
0.324 1.5 2
x 16
ABF M32H151
0.650
3
2
x 16
ABF M32H301
1.150
Inputs or
outputs
(96
channels)
140
DDI 364 00
140
DDO 364 00
2
x 20-way
HE 10
22
0.324 0.5 6
x 16
TSX CDP 053
0.085
1
6
x 16
TSX CDP 103
0.150
2
6
x 16
TSX CDP 203
0.280
3
6
x 16
TSX CDP 303
0.410
5
6
x 16
TSX CDP 503
0.670
Analog inputs
140
AVI 030 00
140
ACI 030 00
1
x 25-way
SUB-D
24
0.22 2
8
ABF M08S201
0.600
140
ACI 040 00
2
x 25-way
SUB-D
24
0.22 2
16
ABF M16S201
0.620
Analog outputs
140
AVO 020 00
1
x 25-way
SUB-D
24
0.22 2
4
ABF M04S200
0.450
140
ACO 020 00
1
x 25-way
SUB-D
24
0.22 2
4
ABF M04S201
0.450
140
ACO 130 00
1
x 25-way
SUB-D
24
0.22 2
8
ABF M04S202
0.450
ABF M32H
pp
1
816500
570464
TSX CDP
p
03
