Connection sub-bases for counter and analog channels
Functions
For PLCs
Compatible
modules
Type of
connection on
Telefast end
Type of
connection
Reference
Weight
kg
Analog and counter
TSX Micro Analog and
integrated
counter
TSX 37 22
TSX CTZ
p
A
15-
way SUB-D Screw
ABE 7CPA01
0.300
Counter, axis control,
position control
Modicon
Premium
TSX CTY
p
A
TSX CAY
p
1
15-
way SUB-D Screw
ABE 7CPA01
0.300
Connection of absolute
encoder with parallel
output
Modicon
Premium
TSX CTY
p
A
TSX CAY
p
1
15-
way SUB-D Screw
ABE 7CPA11
0.330
Distribution of
4
thermocouples
Modicon M340 BMX ART 0414
BMX ART 0814
25-
way SUB-D Screw
ABE 7CPA412
0.180
Distribution of
16
thermocouples
Modicon
Premium
TSX AEY1614 25-way SUB-D Screw
ABE 7CPA12
0.300
Passive distribution
of 8 analog EIS channels
on screw terminals,
with shield continuity
Modicon
Premium
TSX ASY810
TSX AEY1600
TSX A
p
Y800
25-
way SUB-D Screw
ABE 7CPA02
0.290
Modicon M340 BMX AMI 0800
BMX AMI 0810
BMX AMO 0802
Modicon
Quantum
140
AVI 030 00
140
ACI 030 00
140
ACI 040 00
140
ACO 130 00
Provision and
distribution of protected
isolated power supplies
for 4 analog input
channels
Modicon M340 BMX AMI 0410 25-way SUB-D Screw
ABE 7CPA410
0.180
Distribution of 4 analog
output channels
Modicon
Premium
TSX ASY410
TSX AEY420
25-
way SUB-D Screw
ABE 7CPA21
0.210
Modicon M340 BMX AMO 0410
Modicon
Quantum
140
AVO 020 00
140
ACO 020 00
Distribution and
supply of 8 analog
input channels
with limitation of each
current loop
Modicon
Premium
TSX AEY800
TSX AEY1600
25-
way SUB-D Screw
ABE 7CPA03
0.330
Modicon
Quantum
140
AVI 030 00
140
ACI 030 00
140
ACI 040 00
Distribution and supply
of 8 analog input
channels
isolated from
one another with 25 mA/
channel limitation
Modicon
Premium
TSX AEY810 25-way SUB-D Screw
ABE 7CPA31
0.410
Modicon M340 BMX AMI 0800
BMX AMI 0810
BMX AMO 0802
Spring
ABE 7CPA31E
0.410
Modicon
Quantum
140
AVI 030 00
140
ACI 030 00
140
ACI 040 00
Safety
Modicon
Premium
TSX PAY2
p
2 25-
way SUB-D Screw
ABE 7CPA13
0.290
Connection interfaces
Modicon Telefast ABE 7 pre-wired system
Connection sub-bases for analog channels and
application-specific channels
References
ABE 7CPA 21/410/412
ABE 7CPA11
ABE 7CPA01
