Adaptor sub-bases with plug-in relays
Universal input sub-bases for solid state relays, supplied without relays
Number of
channels
No. of
terminals
per channel
For relay type Isolation of
PLC/
Operative
part
Input
connection
Type of
connection
Reference
Weight
kg
16
2
ABS 7E
ABR 7
ABS 7S33E
Yes
Volt-free
Screw
ABE 7P16F310
0.850
Polarity
distribution
Screw
ABE 7P16F312
0.850
Optimum and Universal output sub-bases, supplied with electromechanical relays
(1)
Number of
channels
Relay width Relay type
supplied
Number and
type of
contacts
Polarity distribution/operative
part
Reference
Weight
kg
16
5
mm ABR 7S11 1 N/O
Contact common per group of 4
channels
ABE 7R16T111
0.600
Contact common per group of 4
output channels
+ 2 common input terminals
ABE 7R16M111
(2)
0.600
10
mm ABR 7S21 1 N/O
Volt-free
ABE 7R16T210
0.735
Common on both poles
(3)
ABE 7R16T212
0.730
ABR 7S23 1 C/O
Volt-free
ABE 7R16T230
0.775
Contact common
(3)
ABE 7R16T231
0.730
12
mm ABR 7S33 1 C/O
Volt-free
ABE 7R16T330
1.300
Common on both poles
(4)
ABE 7R16T332
1.200
ABR 7S37 2 C/O
Volt-free
ABE 7R16T370
1.300
(1)
The sub-bases are supplied as standard with electromechanical relays, all or part of which can be replaced by solid state
relays of the same width (it is possible to combine these different technologies on a single sub-base).
(2)
Two connection methods are available, enabling inputs and outputs to be connected to the same sub-base
at the same time.
(3)
Per group of 8 channels.
(4)
Per group of 4 channels.
Connection interfaces
Modicon Telefast ABE 7 pre-wired system
Input/output adaptor sub-bases for or with plug-in relays
References
(
continued)
ABE 7R16M111
ABE 7R16T210
