Modicon Premium automation
platform
0
Uni-Telway serial link
References
(
continued)
Presentation:
page 5/128
Description:
page 5/128
Connections:
page 5/129
TSX PCX 1031
TSX CUSB 1031
References
(
continued)
Uni-Telway bus connecting cables
(1)
Description
Use
Length
Item
no.
Reference
Weight
kg
From
To
RS 485 double shielded
twisted pair cables
Uni-Telway bus
–
100
m
1
TSX CSA 100
5.680
200
m
1
TSX CSA 200
10.920
500
m
1
TSX CSA 500
30.000
Cordsets for
isolated
RS 485 tap link
TSX SCP 114 card TSX SCA 50
T-junction box
3
m
8
TSX SCP CU 4030
0.160
TSX SCA 62
subscriber socket
3
m
–
TSX SCP CU 4530
0.180
TSX SCY 21601
module integrated
channel (ch. 0)
TSX SCA 50
T-junction box
3
m
–
TSX SCY CU 6030
0.180
TSX SCA 62
subscriber socket
3
m
9
TSX SCY CU 6530
0.200
PC terminal (USB
port)
TSX SCA 62
subscriber socket
0.4
m
11
TSX CUSB 485
(2)
0.144
2.5
m
11
TSX CRJDB 25
(2)
0.160
Universal terminal port/
peripheral device cordsets
TSX Micro/ Premium
or TSX PACC 01 box
(
TER or AUX)
RS 232 port for 9-way
SUB D type PC
compatible
2.5
m
11
TSX PCX 1031
0.170
USB port (USB/
RS 485 converter)
0.4
m
–
TSX CUSB 485
(3)
0.144
USB port (Mini-DIN/
RJ45 cordset)
2.5
m
–
TSX CRJMD 25
(3)
0.150
(1)
For other connection cables, see pages 5/132.
(2)
With
TSX CUSB 485
converter, use the
TSX CRJDB 25
cordset (equipped with 1 x 25-way SUB-D and 1 x RJ45).
(3)
With
TSX CUSB 485
converter, use the
TSX CRJMD 25
cordset (equipped with 1 x mini-DIN and 1 x RJ45).
