References
Connecting cables for PCMCIA cards and TER/AUX ports
Modicon TSX Micro/
Premium PLCs
Device to be
connected
Physical link Protocol
Length Reference
Weight
kg
TSX SCP 111
PCMCIA card
DTE terminal
2
RS 232 D Character mode 3 m
TSX SCP CD 1030
0.190
10
m
TSX SCP CD 1100
0.620
DCE terminal
(
Modem, etc.)
2
RS 232 D Character mode
Uni-Telway
3
m
TSX SCP CC 1030
0.190
TSX SCP 114
PCMCIA card
TSX SCA 50
T-junction box
3
RS 485
(2-
wire,
isolated)
Character mode
Uni-Telway
3
m
TSX SCP CU 4030
0.160
RS 422/485
(2-
wire,
isolated)
Character mode
Modbus
3
m
TSX SCP CM 4030
0.160
TSX SCA 62
2-
channel
subscriber
socket
4
RS 485 (2-wire,
isolated)
Uni-Telway
3
m
TSX SCP CU 4530
0.160
TSX SCA 64
2-
channel
subscriber
socket
4
RS 422/485
(2/4-
wire)
Modbus
3
m
TSX SCP CM 4530
0.180
DTE terminal
3
RS 422/485
(4-
wire)
Modbus
3
m
TSX SCP CX 4030
0.160
TSX SCP 112
PCMCIA card
Active or
passive
terminal
3
20
mA current
loop
Character mode
Uni-Telway
Modbus
3
m
TSX SCP CX 2030
0.160
TER/AUX ports
TSX PACC 01
junction box
RS 485
Uni-Telway
1
m Included with TSX PACC 01
TSX PACC 01
junction box
5
RS 485
Uni-Telway
2
m
T FTX CB1 020
0.100
5
m
T FTX CB1 050
0.190
DTE terminal
(
master PC,
printer)
RS 232
6
Character mode 2.5 m
TSX PCX 1031
(1)
0.170
USB
Character mode 0.4 m
TSX CUSB 485
(2)
0.144
2.5
m
TSX CRJMD 25
(2)
0.150
1
25-
way male miniature connector
2
25-
way male SUB-D connector
3
Flying leads
4
15-
way male SUB-D connector
5
8-
way female mini-DIN connector
6
9-
way female SUB-D connector
(1)
See separate parts (page 5/135).
(2)
The
TSX CUSB 485
converter requires the use of the
TSX CRJMD 25
cable (equipped with 1 mini-DIN connector and
1
RJ45 connector).
