Schneider Electric Modicon Premium Automation Platform, May 2012

272 / 413

6/2
Unity Pro programming software for Modicon M340 M, Premium P, Quantum Q, Safety S platforms and Modicon distributed I/O D
IEC 61131-3
languages
Instruction List (IL) M - D M - P - D
Ladder (LD) M - D M - P - D
Structured Text (ST) M - D M - P - D
Function Block Diagram (FBD) M - D M - P - D
Sequential Function Chart (SFC)/Grafcet M - D M - P - D
LL984 Ladder Logic language
Programming
services
Multitask programming (Master, fast and
event-triggered)
M - D M - P - D
Multitask programming (Master, fast,
auxiliary and event-triggered)
Functional view and function modules M - D M - P - D
Block editor and DFB instances M - D M - P - D
DDT compound data editor M - D M - P - D
Data structure instances and tables M - D M - P - D
EF libraries and EFBs M - D M - P - D
User-definable control loops P (TSX P57 2p) - D
Programmable control loops (with process
control FB library)
M - D M - P - D
Safety function block libraries
Motion function block libraries (MFB) M - D M - P - D
Hot Standby PLC redundancy system P (TSX P57 24M) - D
System diagnostics M - D M - P - D
Application diagnostics M - D M - P - D
Diagnostics with location of error source M - D M - P - D
Bus and network configuration to slave
devices (Modicon distributed I/O, etc.)
M - D M - P - D
Debugging
and display
services
PLC simulator M - D M - P - D
Hypertext link animations in graphic
languages
M - D M - P - D
Step-by-step execution, breakpoint M - D M - P - D
Watchpoint M - D M - P - D
Operator screens M - D M - P - D
Diagnostics viewer M - D M - P - D
Other services Creation of hyperlinks M - D M - P - D
XML import/export M - D M - P - D
Application converters (Concept, PL7) M - P - D
Update utilities for PLC and Advantys
operating systems
M - D M - P - D
Communication drivers for Modicon
platforms
M - D M - P - D
Unity Pro servers - Openness
Online modification of configuration
Application imports (Modsoft, Concept,
ProWORX) written in LL984 language
UDE support
OFS exchanges
Dynamic exchange with third-party tools, OFS
Static exchange via XML/XVM export files M - D M - P - D
Compatible
Modicon
platforms
Modicon M340 processors M All models All models
Premium processors P – TSX P57 104M/1634M/154M
TSX P57 204M/2634M/254M
TSX H57 24M
Quantum processors Q – –
Safety processors S – –
Compatible Modicon distributed I/OD STB, OTB, TM7, ETB, Momentum STB, OTB, TM7, ETB, Momentum
Software name Unity Pro Small Unity Pro Medium
Unity Pro software type UNY SPU SFp CD60 UNY SPU MFp CD60
Page/website 6/18 6/19
Selection guide Software
Unity Pro software
