References
Components for asynchronous serial links
(
character mode)
Description
Protocol
Physical layer
Modicon
PLC
Reference
Weight
kg
Integrated link on
processor
Uni-Telway
Character mode
Non-isolated RS 485
TSX Micro Please consult our website
www.schneider-electric.comPremium See pages 1/10 and 1/19
Communication module
Uni-Telway
Modbus/Jbus
Character mode
- 1
isolated RS 485
integrated channel (channel
0), 1
PCMCIA card slot
(
channel 1)
(1)
Premium
TSX SCY 21601
0.360
PCMCIA cards
for TSX 37
21/22
PLCs, Premium
processor
TSX SCY 21601 module
Uni-Telway
Character mode
Modbus
RS 232 (9 signals) 0.3…19.2 Kbps
TSX SCP 111
0.105
RS 485 (RS 422 compatible)
1.2…19.2
Kbps
TSX SCP 114
0.105
20
mACL 1.2…19.2 Kbps
TSX SCP 112
0.105
Asynchronous serial link connection accessories
Description
Use
Reference
Weight
kg
Terminal port connection
box
Isolation of RS 485 signals, line terminator
Supplied with cordset (length 1 m) fitted with a
mini-DIN connector (TER or AUX port).
TSX PACC 01
0.690
Asynchronous serial link connection cordsets
Description
Use
From
To
Length Reference
Weight
kg
Cordsets for isolated RS
485
connection
TSX SCP 114 card RS 485/RS 422
device (2)
3
m
TSX SCP CX 4030
0.160
TSX SCY 21601
module integrated
channel (ch. 0)
RS 485/RS 422
device (3)
via TSX SCA 50 box
3
m
TSX SCY CU 6030
0.180
Universal cordsets for
terminal port/peripheral
device
TSX Micro/Premium
port or TSX PACC
01
box
(
TER or AUX)
RS 232 port of a terminal
device (DTE)
(4)
2.5
m
TSX PCX 1031
0.170
USB port
(
USB/RS 485 converter)
0.4
m
TSX CUSB 485
(5)
0.144
USB port
(
mini-DIN/RJ45 cordset)
2.5
m
TSX CRJMD 25
(5)
0.150
Cordsets for RS 232
connection
TSX SCP 111 card Communication device:
Modem, converter,
(
DCE)
(3)
3
m
TSX SCP CC 1030
0.190
Point-to-point terminal
device (DTE)
(3)
3
m
TSX SCP CD 1030
0.190
10
m
TSX SCP CD 1100
0.620
Cordset for 20 mA CL
connection
TSX SCP 112 card Current loop device
(2)
3
m
TSX SCP CX 2030
0.160
(1)
Type III PCMCIA card slot for for one
TSX SCP 111/112/114
or
TSX FPP 20
card.
(2)
Flying leads on device side.
(3)
End of cable fitted with a male 25-way SUB-D connector.
(4)
End of cable fitted with a female 9-way SUB-D connector. For this application, a
TSX CTC 10
adaptor must be ordered
separately (male 9-way SUB-D/male 25-way SUB-D adaptor).
(5)
The
TSX CUSB 485
converter requires use of a
TSX CRJMD 25
mini-DIN/RJ45 cordset.
Modicon TSX Micro
References
TSX CUSB 485
TSX SCP 11
p
TSX PACC 01
TSX PCX 1031
Modicon Premium automation
platform
Asynchronous serial links
Modicon
Premium
TSX SCY 21601
