References
(
continued)
Modicon Premium automation
platform
0
Connecting cables for PCMCIA cards and
TER/AUX ports
References
(
continued
)
Connecting cables for PCMCIA cards and TER/AUX ports
(
continued)
Modicon TSX Micro/
Premium PLCs
Device to be
connected
Physical link Protocol
Length Reference
Weight
kg
TER/AUX ports
(
continued)
1
DTE terminal
(
slave PC)
2
RS 232 RS
485
Uni-Telway
2.5
m
TSX PCX 1031
0.170
USB
Uni-Telway
0.4
m
TSX CUSB 485
(1)
0.144
2.5
m
TSX CRJMD 25
(1)
0.150
DTE terminal
(
printer, slave
PC without
RTS)
2
RS 232
Character mode
Uni-Telway
2.5
m
TSX PCX 1031
(2)
0.170
RS 232
Character mode
Uni-Telway
0.4
m
TSX CUSB 485
(1)
0.144
2.5
m
TSX CRJMD 25
(1)
0.150
DCE terminal
(
M/Sl. modem
USA/Europe)
3
RS 232
Character mode
Uni-Telway
3
m
TSX PCX 1130
(3)
0.140
Magelis
XBT GT
p
terminal
3
RS 485
Uni-Telway
2.5
m
XBT Z968
+
XBT ZG909
(4)
0.180
5
m
XBT Z9681
+
XBT ZG909
(4)
0.340
TSX SCY 21601
communication module
integrated port
4
TSX SCA 50
T-junction
box
5
RS 485
(2-
wire,
isolated)
Uni-Telway
3
m
TSX SCY CU 6030
0.180
Modbus
3
m
TSX SCY CM 6030
0.180
TSX SCA 62
2-
channel
subscriber
socket
6
RS 485 (2-wire,
isolated)
Uni-Telway
3
m
TSX SCY CU 6530
0.200
RS 485
terminal
5
RS 485 (2-wire,
isolated)
Character mode 3 m
TSX SCY CM 6030
0.180
Separate parts
Designation
Description
Reference
Weight
kg
SUB-D adaptors
9-
way male SUB-D/25-way female SUB-D
TSX CTC 07
0.060
9-
way male SUB-D/25-way male SUB-D
TSX CTC 10
0.060
1
8-
way female mini-DIN connector
2
9-
way female SUB-D connector
3
9-
way male SUB-D connector
4
25-
way male SUB-D connector
5
Flying leads
6
15-
way male SUB-D connector
(1)
The
TSX CUSB 485
converter requires the use of the
TSX CRJMD 25
cable (equipped with 1 mini-DIN connector and 1
RJ45 connector).
(2)
To be ordered separately:
TSX CTC 07
and
TSX CTC 10
adaptors, see separate parts above.
(3)
Point-to-point, supplied with 1
TSX CTC 09
9-
way female/25-way male SUB-D adaptor.
(4)
For connection to Magelis XBT GK/GW terminals, please refer to the “Human-Machine Interfaces” catalogue.
