Modicon Premium automation
platform
Modbus serial link
References
(
continued)
Modbus serial link connecting cable
Description
Use
Length Reference
Weight
kg
From
To
RS 485 double
shielded twisted pair
trunk cables
Modbus serial link
–
100
m
TSX CSA 100
5.680
200
m
TSX CSA 200
10.920
500
m
TSX CSA 500
30.000
Cables for
isolated
RS 422/485 tap link
TSX SCP 114 card
TSX SCA 50 T-junction
box, 2 wires
(1)
3
m
TSX SCP CM 4030
0.160
TSX SCA 62 subscriber
socket, 2/4 wires
3
m
TSX SCP CM 4530
0.180
Modbus standard device,
4
wires
(1)
(
point-to-point)
3
m
TSX SCP CX 4030
0.160
Premium
TSX SCY 11601,
TSX SCY 21601
module integrated
channel (ch. 0)
TSX SCA 50 T-junction
box, 2 wires
(1)
3
m
TSX SCY CM 6030
0.160
TSX SCA 62 subscriber
socket, 2 wires
3
m
TSX SCY CM 6530
0.160
Modbus RS 485
cordsets
Twido and TSX Micro
terminal port
(
Mini-DIN connector)
TWD XCA ISO isolation
box (RJ45 connector)
0.3
m
TWD XCA RJ003
0.040
1
m
TWD XCA RJ010
0.090
3
m
TWD XCA RJ030
0.160
RS 232 tap link
cordsets
TSX SCP 111 card Communication device
(
Modem, converter, etc)
(
DCE)
(2)
3
m
TSX SCP CC 1030
0.190
Terminal device with
point-to-point (DTE)
(2)
3
m
TSX SCP CD 1030
0.190
10
m
TSX SCP CD 1100
0.620
Corset for tap link
20
mACL
TSX SCP 112 card Modbus multidrop
(1)
3
m
TSX SCP CX 2030
0.160
Other connecting
cables
–
–
–
See page 5/134
–
(1)
End of cordset with free wires.
(2)
End of cordset equipped with a male 25-pin SUB-D connector.
